Interface Vigor2952
|
| WAN Port |
1x GbE/SFP Combo port + 1x GbE port |
| LAN Port |
4x GbE |
| USB Port |
1x USB 3.0 + 1x USB 2.0 |
Performance Vigor2952
|
| NAT Throughput |
500 Mbps |
| NAT Throughput w/ Hardware Acceleration |
900 Mbps |
| IPsec VPN Performance |
200 Mbps (AES 256 bits) |
| SSL VPN Performance |
90 Mbps |
| Max. Number of NAT Sessions |
60,000 |
| Max. Concurrent VPN Tunnels |
200 |
| Max. Concurrent OpenVPN + SSL VPN |
50 |
Internet Connection
|
| IPv4 |
PPPoE, DHCP, Static IP, PPTP/L2TP |
| IPv6 |
PPP, DHCPv6, Static IP, TSPC, AICCU, 6rd, 6in4 Static Tunnel |
| Multi-VLAN/PVC |
|
| 3G/4G/LTE WAN with USB modem |
|
| Load Balancing |
IP-based, Session-based |
| WAN Active on Demand |
Link Failure, Traffic Threshold |
| Connection Detection |
ARP, Ping |
| WAN Data Budget |
|
| Dynamic DNS |
|
| DrayDDNS |
|
LAN Management
|
| VLAN |
802.1q Tag-based, Port-based |
| Max. Number of VLAN |
8 |
| Number of LAN Subnet |
8 |
| DHCP Server |
Multiple IP Subnet, Custom DHCP Options, Bind-IP-to-MAC |
| LAN IP Alias |
|
| PPPoE Server |
|
| Port Mirroring |
|
| Local DNS Server |
|
| Conditional DNS Forwarding |
|
| Hotspot Web Portal |
|
| Hotspot Authentication |
Click-Through, Social Login, SMS PIN, Voucher PIN, RADIUS, External Portal Server |
Networking
|
| Routing |
IPv4 Static Routing, IPv6 Static Routing, Inter-VLAN Routing, RIP, BGP |
| Policy-based Routing |
Protocol, IP Address, Port, Domain, Country |
| High Availability |
|
| DNS Security (DNSSEC) |
|
| Multicast |
IGMP Proxy, IGMP Snooping, Bonjour |
| Local RADIUS server |
|
| SMB File Sharing |
(Requires external storage) |
VPN
|
| LAN-to-LAN |
|
| Teleworker-to-LAN |
|
| Protocols |
PPTP, L2TP, IPsec, L2TP over IPsec, SSL, GRE, IKEv2, IKEv2-EAP, IPsec XAuth, OpenVPN(Host to LAN) |
| User Authentication |
Local, RADIUS, LDAP, TACACS+, mOTP |
| IKE Authentication |
Pre-Shared Key, X.509 |
| IPsec Authentication |
SHA-1, SHA-256, MD5 |
| VPN Redundancy |
Load Balancing, Failover |
| Single-Armed VPN |
|
| NAT-Traversal (NAT-T) |
|
| DrayTek VPN Matcher |
|
Firewall & Content Filtering
|
| NAT |
Port Redirection, Open Ports, Port Triggering, DMZ Host, UPnP |
| ALG (Application Layer Gateway) |
SIP, RTSP, FTP, H.323, TFTP |
| VPN Pass-Through |
PPTP, L2TP, IPsec |
| IP-based Firewall Policy |
|
| Content Filtering |
Application, URL, DNS Keyword, Web Features, Web Category* (*: subscription required) |
| DoS Attack Defense |
|
| Spoofing Defense |
|
Bandwidth Management
|
| IP-based Bandwidth Limit |
|
| IP-based Session Limit |
|
| QoS (Quality of Service) |
TOS, DSCP, 802.1p, IP Address, Port, Application |
| VoIP Prioritization |
|
Management
|
| Local Service |
HTTP, HTTPS, Telnet, SSH v2, TR-069, FTP, SNMP |
| Config File Export & Import |
|
| Config File Compatibility |
Vigor2925, Vigor2920, Vigor2930, Vigor2950, Vigor2955 |
| Firmware Upgrade |
TFTP, HTTP, TR-069 |
| 2-Level Administration Privilege |
|
| Access Control |
Access List, Brute Force Protection |
| Syslog |
|
| Notification Alert |
SMS, E-mail |
| SNMP |
v1, v2c, v3 |
| Managed by VigorACS |
|
| Central VPN Management |
8 VPN |
| Central AP Management |
30 VigorAP |
| Central Switch Management |
10 VigorSwitch |
Physical
|
| Rack Mountable |
Mouting Kit Included |
| Power Supply |
AC 110-220V @ 1A |
| Max. Power Consumption |
15 watts |
| Dimension |
273mm x 171mm x 45mm |
| Weight |
1.94kg |
| Operating Temperature |
0 to 45°C |
| Storage Temperature |
-20 to 70°C |
| Operating Humidity |
10 to 90% (non-condensing) |
| Certificate |
  |
