Detection Performance

• Detection MethodOpening Contact
• Detection Gap52mm Max

Feature

• Digital ProcessingSupport
• Tamper ProtectionFront;Rear
• Environment Temperature IndicatorSupport
• Signal Strength IndicatorSupport

Interface

• Power SwitchPower Up Enrolling
• LED IndicatorBlue (Alarm)

Transmission

• Transmission TechnologyTri-X Wireless
• Transmission MethodTwo-Way RF Wireless
• Transmission Frequency433MHz
• Transmission SecurityAES-128 Encryption
• Transmission Range(Free Space)1Km
• Frequency HoppingSupport
• Enrolling MethodPower up;Remote ID;QR Code

Electrical Characteristics

• Standard Battery Life

  3 years in work status (being triggered 20 times per day)

• Power SupplyBattery Powered
• Battery TypeCR2450 x 1
• Typical Voltage3V

• General
• Operation Temperature-10 °C to 55 °C (14 °F to 131 °F)
• Storage Temperature-20 °C to 60 °C (-4 °F to 140 °F)
• Operation Humidity10% to 90%
• Dimension(WxHxD)

  29mm × 69mm × 10mm

  14mm × 69mm × 10mm

• Weight38g
• Mounting MethodWall-mount(The device only supports wooden structure installation and cannot be installed on metal surface)
• Application ScenarioIndoor
