Hardware features

• Serial port1
• Tamper-ProofSupported, front and rear
• BuzzerSupported
• Power switchPower on/off
• MicSupported

Electrical characteristics

• Operation humidity10% to 90% (no condensing)
• Operation temperature–10°C~55°C
• Battery typeFour CR123 batteries
• Power supplySupport 12VDC Power Supply
• Power interface12VDC
• Power consumption

  Quiescent current: 25 uA

  Max current: 1.6 A

  Voltage: 3 V

• Battery life spanUp to 2 years (Alarm once a week, 5 mins alarm and 5 mins talk)

Wireless transmission

• RF frequency433 MHz
• RF modulation2GFSK
• RF distance800m (open area)
• Wireless technologyCAM-X Wireless Technology

Display

• LED IndicatorEnrollment/Signal (red/green), Alarm(Blue/Red), Two-way audio service(Blue/Red)

General

• Dimension(WxHxD)130 × 128 × 39.5 mm
• ColorWhite Case (Blue or Red LED Alarm)
• Installation methodWall mounting
• Weight361.0 g
