Specifications DAHUA EAP6218-O
| Features |
Description |
| Product Type |
AX18 Outdoor Wireless Access Point |
| Wireless Standard |
IEEE 802.11a/b/g/n/ac/ax |
| Wireless Speed |
2.4 GHz: 574 Mbps; 5 GHz: 1201 Mbps; Total: 1.775 Gbps |
| Antenna Gain |
6 dBi @ 2.4 GHz / 6 dBi @ 5 GHz |
| Ethernet Port |
1 × 10/100/1000 Mbps RJ-45, WAN/PoE |
| Power Supply |
PoE 802.3at |
| Protection |
IP67 |
| Wireless |
| Wireless Standard |
2.4 GHz: IEEE 802.11b/g/n/ax
5 GHz: IEEE 802.11a/n/ac/ax |
| Operating Frequency |
2.4 GHz–2.484 GHz; 5.150 GHz–5.850 GHz |
| Wireless Transmission Rate |
2.4 GHz: 574 Mbps; 5 GHz: 1201 Mbps |
| Channel Width |
20 / 40 / 80 MHz |
| Antenna Gain |
6 dBi @ 2.4 GHz; 6 dBi @ 5 GHz |
| Antenna Direction Angle |
360° |
| MU-MIMO |
Yes |
| DFS |
Yes |
| Optimal Transmission Distance |
Up to 100 m |
| Network & Management |
| Ethernet Interface |
1 × 10/100/1000 Mbps Base-T RJ-45 |
| Operating Mode |
FIT AP / FAT AP |
| VLAN |
VLAN configuration based on SSID |
| DHCP |
Supported |
| NAT |
Port Mapping / DMZ |
| QoS |
IP-based Speed Limit |
| DDNS |
Supported |
| Management |
Local Web Management / AC Remote Management |
| Firmware Update |
Web Update / AC Remote Update |
| Security |
| Encryption |
WPA-PSK / WPA2-PSK / WPA3-PSK |
| SSID Security |
SSID Hiding |
| MAC Authentication |
Supported |
| IP-MAC Binding |
Supported |
| User Isolation |
Supported |
| URL Filtering |
Supported |
| IP/MAC Filtering |
Supported |
| Features |
| Seamless Roaming |
Supported |
| SSID Extension |
Supported |
| Auto Channel |
Supported |
| Power Adjustment |
Supported |
| 5 GHz Precedence |
Supported |
| Wi-Fi Timer |
Supported |
| VPN Pass-through |
Supported |
| Syslog |
Supported |
| NTP |
Supported |
| Hardware & Power |
| Memory |
DDR: 512 MB; Flash: 8 MB; NAND: 128 MB |
| Power Supply |
PoE 802.3at |
| Power Consumption |
16 W (Full Load) |
| Indicator |
SYS / WAN-PoE / LAN / 2.4G / 5G |
| Installation |
Pole Mount |
| Physical & Environment |
| Product Dimensions |
304 × 181 × 88 mm |
| Net Weight |
1.06 kg |
| Operating Temperature |
-20°C to +55°C |
| Storage Temperature |
-40°C to +70°C |
| Operating Humidity |
5%–95% RH |
| Static Protection |
Air Discharge: 8 kV; Contact Discharge: 6 kV |
| Lightning Protection |
Common Mode: 4 kV; Differential Mode: 2 kV |
| Protection |
IP67 |
| Certifications |
CE / FCC |
Note: The DAHUA EAP6218-O is an outdoor Wi-Fi 6 dual-band access point with 574 Mbps on 2.4 GHz and 1201 Mbps on 5 GHz, supporting FIT AP and FAT AP modes.
Important: Specifications are based on the current official Dahua EAP6218-O datasheet and product information. Actual wireless coverage may vary depending on installation height, obstacles, interference, client devices, and environmental conditions.
