Auxiliary Interface

• SATA1 SATA interfaces
• CapacityUp to 6 TB capacity for each disk
• USB Interface2 × USB 2.0

Network

• Network Interface1, RJ45 10M/100M self-adaptive Ethernet interface
• Remote Connections32
• Network ProtocolsTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS

Analog Video Input

• Analog Video Input4-ch;BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
• HDTVI Input1080p25, 1080p30, 720p25, 720p30
• AHD Input1080p25, 1080p30, 720p25, 720p30
• HDCVI Input1080p25, 1080p30, 720p25, 720p30
• CVBS InputSupport
• HDMI1/VGA Output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
• Audio Input1-ch, RCA (2.0 Vp-p, 1 KΩ)
• Audio Output1-ch, RCA (Linear, 1 KΩ)
• Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KΩ)

Video And Audio

• IP Video Input

  1-ch (up to 5-ch)

  Up to 1080p resolution

• Recording
• Video CompressionH.264+/H.264
• Encoding Resolution

  When 1080p lite mode not enabled: 720p/WD1/4CIF/VGA/CIF

  When 1080p lite mode enabled: 1080p lite/HD 720p lite/WD1/4CIF/VGA/CIF

• Frame Rate

  Main stream:

  When 1080p lite mode enabled:

  1080p lite/HD 720p lite/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)

  When 1080p lite mode not enabled:

  For 720p stream access:

  720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)

  For SD stream access:

  WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)

  Sub-stream:

  CIF/QVGA/QCIF@25fps (P)/30fps (N)

• Video Bit Rate32 Kbps to 6 Mbps
• Dual StreamSupport
• Stream TypeVideo, Video & Audio
• Audio CompressionG.711u
• Audio Bit Rate64 Kbps

General

• Power Supply12 VDC
• Consumption (Without HDD)≤ 8 W
• Working Temperature-10 ºC to +55 ºC (14 ºF to 131 ºF)
• Working Humidity10% to 90%
• Dimensions (W × D × H)200 × 200 × 45 mm (7.9 × 7.9 × 1.8 inch)
• Weights (Without HDD)≤ 0.8 kg (1.8 lb)
