| Camera |
| Image Sensor: |
|
1/2.8” CMOS progressive scan CMOS |
| Min. Illumination: |
|
Color: 0.005 Lux @ (F1.2, AGC ON)
Color: 0.0089 Lux @(F1.6, AGC ON)
0 Lux with IR on |
| Shutter time: |
|
1/25 s to 1/100,000 s |
| Slow shutter: |
|
No |
| Lens: |
|
Two identical lenses. 4 mm, 6 mm, 8mm, 12mm, optional |
| Adjustment Range: |
|
Tilt: -45° to 90°, rotate: 0° to 355° |
| Wide Dynamic Range: |
|
120 dB |
| Compression Standard |
| Video Compression: |
|
H.265+/H.265/H.264+/H.264/MJPEG |
| Video bit rate: |
|
32Kbps~16Mbps |
| Audio Compression: |
|
G.711/G.722.1/G.726/MP2L2 |
| Audio bit rate: |
|
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2) |
| Image |
| Max. Image Resolution: |
|
1920 x 1080 |
| Frame Rate: |
|
50Hz: 25fps (1920 × 1080, 1280 × 720)
60Hz: 30fps (1920 × 1080, 1280 × 720) |
| Sub Stream: |
|
50Hz: 25fps (704 × 576, 640 × 480, 352 × 288)
60Hz: 30fps (704 × 480, 640 × 480, 352 × 240) |
| Third Stream: |
|
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480, 352 × 240) |
| Image Enhancement: |
|
BLC, HLC, defog, EIS, lens distortion correction, 3D DNR |
| Image Settings: |
|
Saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser |
| Picture Overlay: |
|
LOGO picture can be overlaid on video with 128 × 128 24bit bmp format |
| Day/Night Switch: |
|
Auto/Schedule/Triggered by Alarm In |
| Network |
| Network Storage: |
|
Support Micro SD/SDHC/SDXC card (128G), local storage and ANR |
| Protocols: |
|
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
| Intelligent |
| Face Capture: |
|
Capture, automatically select and output optimum face picture.
Instantly compare captured face pictures with those in face picture libraries.
Recognized faces trigger alarm if alarm action is configured. |
| Interface |
| Audio: |
|
1 input, 1 output |
| Communication Interface: |
|
1 RJ45 10M/100M/1000M Ethernet port, 1 RS-485 interface |
| Alarm: |
|
1 input, 1 output (up to 24 VDC 1 A or 110 VAC 500 mA) |
| On-board storage: |
|
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Audio |
| Environment Noise Filtering: |
|
Support |
| Audio I/O: |
|
support |
| General |
| IR Range: |
|
Up to 10 m |
| Operation Condition: |
|
-10 °C to 40 °C (-14 °F to 104 °F)
Humidity 95% or less (non-condensing) |
| Power Consumption: |
|
36 VDC, max. 27 W, 0.75A |
| Dimensions: |
|
180.4 × 147 × 117.9 mm (7.10″ × 5.79″ × 4.64″) |
| Weight: |
|
Approx. 1500 g (3.31 lb) |
|
