| Features |
Description |
| Product Type |
4MP WizColor Fixed-focal Eyeball WizSense Network Camera |
| Image Sensor |
1/1.8″ Progressive Scan CMOS |
| Maximum Resolution |
2688 × 1520 |
| Lens |
Fixed-focal 2.8mm / 3.6mm |
| Minimum Illumination |
0.0001 Lux @ F1.0 |
| WDR |
120dB |
| Smart Features |
SMD Plus / Human & Vehicle Classification |
| Illumination |
Warm Light up to 30m |
| Audio |
Built-in Microphone |
| Protection |
IP67 |
| CAMERA |
| Image Sensor |
1/1.8″ Progressive Scan CMOS |
| Maximum Resolution |
2688 × 1520 |
| Maximum Frame Rate |
20fps at 2688 × 1520 / 25/30fps at 2560 × 1440 |
| Minimum Illumination |
0.0001 Lux @ F1.0 |
| Electronic Shutter |
Auto / Manual, 1/3s–1/100,000s |
| S/N Ratio |
>56dB |
| Day/Night |
Auto / Color / B/W |
| Wide Dynamic Range |
120dB |
| Noise Reduction |
3D NR |
| Backlight Compensation |
BLC / HLC |
| LENS |
| Lens Type |
Fixed-focal |
| Lens Mount |
M16 |
| Focal Length |
2.8mm / 3.6mm |
| Maximum Aperture |
F1.0 |
| Iris Control |
Fixed |
| Field of View – 2.8mm |
H: 105° / V: 57° / D: 125° |
| Field of View – 3.6mm |
H: 89° / V: 48° / D: 105° |
| Close Focus Distance – 2.8mm |
2.0m |
| Close Focus Distance – 3.6mm |
3.0m |
| DORI |
| 2.8mm Detect |
57.9m |
| 2.8mm Observe |
23.2m |
| 2.8mm Recognize |
11.6m |
| 2.8mm Identify |
5.8m |
| 3.6mm Detect |
70.3m |
| 3.6mm Observe |
28.1m |
| 3.6mm Recognize |
14.1m |
| 3.6mm Identify |
7.0m |
| ILLUMINATION |
| Light Type |
Warm Light |
| Illuminator |
2 × Warm Light |
| Illumination Distance |
Up to 30m |
| Illuminator Control |
Auto / Manual |
| VIDEO |
| Video Compression |
H.265 / H.264 / H.264H / H.264B / MJPEG |
| Smart Codec |
Smart H.265+ / Smart H.264+ |
| Main Stream |
2688 × 1520 @ 1–20fps / 2560 × 1440 @ 1–25/30fps |
| Sub Stream |
704 × 576 @ 1–25fps / 704 × 480 @ 1–30fps |
| Stream Capability |
2 Streams |
| Video Bit Rate |
H.264: 32Kbps–6144Kbps / H.265: 12Kbps–6144Kbps |
| Bit Rate Control |
CBR / VBR |
| ROI |
Supported |
| Privacy Masking |
4 Areas |
| Digital Watermarking |
Supported |
| SMART FEATURES |
| IVS |
Intrusion / Tripwire |
| Target Classification |
Human / Vehicle |
| SMD |
SMD Plus |
| Smart Search |
Supported with Smart NVR |
| Motion Detection |
Supported |
| Video Tampering Detection |
Supported |
| Audio Detection |
Supported |
| Voltage Detection |
Supported |
| AUDIO |
| Built-in Microphone |
Supported |
| Audio Compression |
G.711a / G.711Mu / PCM / G.726 |
| Audio Detection |
Supported |
| NETWORK |
| Network Interface |
1 × RJ45 10/100Mbps Ethernet Port |
| PoE |
IEEE 802.3af |
| Network Protocols |
IPv4 / IPv6 / HTTP / TCP / UDP / ARP / RTP / RTSP / RTCP / RTMP / SMTP / FTP / SFTP / DHCP / DNS / DDNS / QoS / UPnP / NTP / Multicast / ICMP / IGMP / NFS / PPPoE / P2P / Bonjour |
| Interoperability |
ONVIF Profile S / Profile G / Profile T / Profile M / CGI |
| Maximum Users |
20 Users |
| Total Bandwidth |
48Mbps |
| Security |
HTTPS / 802.1X / IP-MAC Filtering / Account Lockout / Security Logs / X.509 / Trusted Boot / Trusted Execution / Trusted Upgrade |
| Management Software |
SmartPSS Lite / DSS / DMSS |
| Mobile Client |
iOS / Android |
| STORAGE |
| MicroSD |
MicroSD Card up to 256GB |
| Storage |
FTP / SFTP / MicroSD / NAS |
| Smart Search |
Supported with Smart NVR |
| POWER |
| Power Supply |
12VDC ±30% / PoE |
| PoE Standard |
IEEE 802.3af |
| Basic Power Consumption |
1.7W @ 12VDC / 2W @ PoE |
| Maximum Power Consumption |
4.9W @ 12VDC / 5.5W @ PoE |
| PROTECTION |
| Ingress Protection |
IP67 |
| Anti-Corrosion |
Basic Protection |
| Operating Temperature |
-40°C to +60°C |
| Operating Humidity |
≤95% RH, Non-Condensing |
| Storage Temperature |
-40°C to +60°C |
| Storage Humidity |
≤95% RH, Non-Condensing |
| POWER & GENERAL |
| Power Supply |
12VDC / PoE |
| Maximum Power Consumption |
5.5W @ PoE |
| Dimensions |
109.5 × Ø109.9mm |
| Material |
Metal Inner Core + Plastic Cover |
| Net Weight |
0.39kg |
| Operating Temperature |
-40°C to +60°C |
| Protection Rating |
IP67 |
Note: The Dahua IPC-HDW2449T-S-PRO is a 4MP WizColor Fixed-focal Eyeball WizSense Network Camera featuring a 1/1.8″ CMOS sensor, 2688 × 1520 resolution, 2.8mm or 3.6mm fixed-focal lens and F1.0 aperture. It supports 120dB WDR, Smart H.265+/H.264+, SMD Plus, human and vehicle classification, intrusion and tripwire detection, built-in microphone, MicroSD storage up to 256GB and warm-light illumination up to 30m.
Important: The Dahua IPC-HDW2449T-S-PRO is a 4MP WizColor Eyeball Network Camera with a 1/1.8″ CMOS sensor, 2.8mm or 3.6mm fixed-focal lens, F1.0 aperture and 120dB WDR. It supports SMD Plus, human and vehicle classification, intrusion, tripwire, Smart H.265+/H.264+, built-in microphone and up to 256GB MicroSD storage. The camera supports 12VDC and IEEE 802.3af PoE and features IP67 protection for outdoor installation.
