| Features |
Description |
| Product Type |
Layer 2 Unmanaged Non-PoE Switch |
| Series |
RG-ES100 Series |
| Total Ports |
24 × 10/100/1000BASE-T |
| PoE Support |
Not Supported |
| Switching Capacity |
48Gbps |
| Forwarding Rate |
35.70Mpps |
| MAC Address Table |
8K |
| Management |
Unmanaged / Visible on Ruijie Cloud |
| HARDWARE |
| RJ45 Ports |
24 × 10/100/1000BASE-T |
| Port Speed |
10/100/1000Mbps Auto-Negotiation |
| PoE |
Not Supported |
| MAC Address Table |
8K |
| Switch Buffer |
4.1Mbit |
| Fan |
Fanless |
| Mounting |
Desktop / 19-inch Rack Mount |
| PERFORMANCE |
| Switching Capacity |
48Gbps |
| Forwarding Rate |
35.70Mpps |
| MAC Address Capacity |
8K |
| Packet Buffer |
4.1Mbit |
| PoE Power Budget |
Not Applicable |
| NETWORK FEATURES |
| Operating Modes |
Flow Control On / Flow Control Off / Port Isolation / Extend Data Transmission |
| Flow Control |
Supported |
| Port Isolation |
Supported |
| Auto MDI/MDIX |
Supported |
| Auto-Negotiation |
Supported |
| Half/Full Duplex |
Supported |
| Store and Forward |
Supported |
| Plug & Play |
Supported |
| Extend Data Transmission |
Up to 250m at 10Mbps on Ports 1–8* |
| MANAGEMENT |
| Switch Management |
Unmanaged |
| Cloud Visibility |
Visible on Ruijie Cloud |
| Cloud Configuration |
Not Supported |
| Web Management |
Not Supported |
| SNMP |
Not Supported |
| Remote Management |
Not Supported |
| PROTECTION |
| Port Surge Protection |
Common Mode ±4kV |
| Power Surge Protection |
Common Mode ±6kV / Differential Mode ±6kV |
| Port Isolation |
Supported |
| Flow Control Protection |
Supported |
| POWER & GENERAL |
| Power Supply |
Internal AC Power Supply |
| Input Voltage |
100–240VAC |
| Input Frequency |
50/60Hz |
| Maximum Power Consumption |
16W |
| Installation |
Desktop / 19-inch Rack Mount |
| Dimensions |
280 × 126 × 44mm |
| Operating Temperature |
0°C to 45°C |
| Storage Temperature |
-40°C to 70°C |
| Operating Humidity |
10%–90% RH, Non-Condensing |
| Storage Humidity |
5%–95% RH, Non-Condensing |
| Fan |
Fanless |
| MTBF |
>200,000 Hours |
| Warranty |
3 Years |
Note: The Ruijie Reyee RG-ES124GD is a 24-port Layer 2 Unmanaged Gigabit Non-PoE Switch featuring 24 × 10/100/1000BASE-T ports. It provides 48Gbps switching capacity, 35.70Mpps forwarding performance, an 8K MAC address table and a 4.1Mbit packet buffer. The switch supports Flow Control, Port Isolation, Auto MDI/MDIX, Auto-Negotiation, Plug & Play and Extended Data Transmission up to 250m at 10Mbps on Ports 1–8. It features a fanless design and can be visible on Ruijie Cloud when at least one managed switch is deployed on the same network.
Important: The Ruijie Reyee RG-ES124GD is a 24-Port Gigabit Unmanaged Non-PoE Switch featuring 24 × 10/100/1000BASE-T ports. It provides 48Gbps switching capacity, 35.70Mpps forwarding performance and an 8K MAC address table. The switch supports Flow Control, Port Isolation, Auto MDI/MDIX and Extend Data Transmission. It has a fanless design, dimensions of 280 × 126 × 44mm and a 3-year warranty.
