| Features |
Description |
| Product Type |
6-Port Cloud Managed Layer 2 Industrial PoE Switch |
| RJ45 Ports |
4 x 10/100/1000BASE-T |
| SFP Ports |
2 x 1G SFP |
| PoE Ports |
4 PoE Ports: 3 x PoE+ and 1 x PoE++ |
| PoE Standard |
IEEE 802.3af/at/bt |
| PoE Budget |
Default: 108 W, Maximum: 180 W |
| PoE++ Output |
Up to 90 W |
| Switching Capacity |
12 Gbps |
| Forwarding Rate |
8.9 Mpps |
| Layer |
Layer 2 |
| Management |
Ruijie Cloud and Web Management |
| Installation |
DIN Rail / Wall Mount |
| INDUSTRIAL FEATURES |
Description |
| Operating Temperature |
-40°C to 75°C |
| Housing |
Full Aluminum Casing |
| Surge Protection |
6 kV |
| EMC |
Level 4 |
| PoE Watchdog |
Supported |
| Port Isolation |
Supported |
| ERPS |
Supported |
| Self-Organizing Network |
Supported |
| NETWORK FEATURES |
Description |
| VLAN |
Supports VLAN Configuration |
| STP/RSTP |
Supported |
| ERPS |
Supported |
| IGMP Snooping |
Supported |
| QoS |
Supported |
| Storm Control |
Supported |
| Loop Prevention |
Supported |
| GENERAL |
Description |
| Warranty |
5 Years |
| Power Supply |
Power Adapter Not Included |
| Shipping Weight |
Approx. 1.08 kg |
Note: The Ruijie Reyee RG-NIS2100-4GT2SFP-HP is a 6-port Cloud Managed Layer 2 industrial PoE switch featuring 4 Gigabit RJ45 ports, 2 Gigabit SFP uplink ports, 3 PoE+ ports, and 1 PoE++ port with up to 90 W PoE output.
Important: The switch is designed for harsh industrial environments with a -40°C to 75°C operating temperature range, full aluminum casing, 6 kV surge protection, Level 4 EMC, DIN rail mounting, ERPS, PoE Watchdog, and Ruijie Cloud management.
