Camera

• Image Sensor2 MP CMOS
• Signal SystemPAL/NTSC
• Resolution1920 (H) × 1080 (V)
• Frame Rate

  TVI: 1080p@25fps/30fps

  CVI: 1080p@25fps/30fps

  AHD:1080p@25fps/30fps

  CVBS: PAL/NTSC

• Min. Illumination0.001 Lux @ (F1.0, AGC ON)， 0 Lux with white light
• Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
• Lens2.8 mm/3.6 mm/6 mm fixed lens
• Field Of View

  2.8 mm, horizontal FOV: 102°, vertical FOV: 54°, diagonal FOV: 121°

  3.6 mm, horizontal FOV: 80°, vertical FOV: 43°, diagonal FOV: 95°

  6 mm, horizontal FOV: 52°, vertical FOV: 29°, diagonal FOV: 61°

• Lens MountM12
• Light AlarmSolid Light Alarm (White Light)
• Day & Night24/7 Color Imaging
• WDR (Wide Dynamic Range)Digital WDR
• Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360°


• White LightAuto/Off
• Image ModeSTD/HIGH-SAT/HIGHLIGHT
• AGCYes
• Day/Night ModeColor
• White BalanceAuto/Manual
• AE (Auto Exposure) ModeDWDR;BLC;HLC;Global
• Noise Reduction3D DNR/2D DNR
• LanguageEnglish
• FunctionBrightness;Contrast;Mirror;Defective Pixel Correction;Sharpness;Anti-Banding;Smart Light
• Lighting ModeWhite Light

Interface

• Video OutputSwitchable TVI/AHD/CVI/CVBS

• General
• Operating Conditions-40°C to 60°C (-40°F to140°F), Humidity: 90% or less (non-condensing)
• Power Supply

  12 VDC±25%

  *You are recommended to use one power adapter to supply the power for one camera.

• ConsumptionMax. 2.4 W
• Protection LevelIP66
• MaterialPlastic
• White Light RangeUp to 20 m
• Dimension162.7 mm × 70 mm × 70 mm (6.41″ × 2.75″ × 2.75″)
• Approx. 152.5 g (0.34 lb.)
