| Features |
Description |
| Device Type |
6-Port 10/100Mbps Desktop Switch with 3-Port PoE+ |
| Network Ports |
3 × 10/100Mbps PoE+ RJ45 Ports, 2 × 10/100Mbps RJ45 Ports, 1 × 10/100Mbps RJ45 Uplink |
| PoE Standard |
IEEE 802.3af |
| PoE Ports |
Ports 1–3 |
| PoE Power |
Up to 15.4 W per PoE Port |
| PoE Budget |
40 W |
| Transmission Distance |
Up to 250 m in Extend Mode |
| Isolation Mode |
Separates PoE Ports from Each Other to Improve Network Security |
| PoE Auto Recovery |
Automatically Detects and Reboots Unresponsive PoE Devices |
| Switching Capacity |
1.2 Gbps |
| Packet Forwarding Rate |
0.8928 Mpps |
| Application |
IP Cameras, VoIP Phones, Access Points and Small Surveillance Networks |
| Interface |
3 × 10/100Mbps PoE+ RJ45, 3 × 10/100Mbps RJ45 |
| PoE Standard |
IEEE 802.3af |
| PoE Ports |
Ports 1–3 |
| PoE Power |
Up to 15.4 W per Port |
| Total PoE Budget |
40 W |
| Network Speed |
10/100Mbps |
| Switching Capacity |
1.2 Gbps |
| Packet Forwarding Rate |
0.8928 Mpps |
| MAC Address Table |
2K |
| Jumbo Frame |
2 KB |
| Transmission Method |
Store-and-Forward |
| Auto Negotiation |
Supported |
| Auto MDI/MDIX |
Supported |
| Extend Mode |
Up to 250 m |
| Isolation Mode |
Supported |
| PoE Auto Recovery |
Supported |
| Flow Control |
IEEE 802.3x Flow Control |
| Fan |
Fanless |
| Power Supply |
48 VDC / 0.85 A External Power Adapter |
| Maximum Power Consumption |
48.8 W |
| SMART FEATURES |
| 3-Port PoE+ |
Provides Three 10/100Mbps PoE Ports Supporting IEEE 802.3af Devices with Up to 15.4 W per Port |
| 40W PoE Budget |
Provides Up to 40 W Total PoE Power for IP Cameras, Access Points and VoIP Devices |
| 250m Extend Mode |
Extends PoE Data and Power Transmission Distance up to 250 m for Long-Distance Surveillance Deployments |
| PoE Auto Recovery |
Automatically Detects Unresponsive PoE Devices and Reboots Them to Maintain Stable Operation |
| Isolation Mode |
Separates PoE Port Traffic to Improve Network Security and Reduce Network Interference |
| Fanless Design |
Silent Fanless Construction Provides Reliable Operation with Low Noise and Low Maintenance |
| GENERAL |
| Switch Type |
Unmanaged PoE+ Desktop Switch |
| PoE Ports |
3 × 10/100Mbps PoE+ |
| Uplink Ports |
3 × 10/100Mbps RJ45 |
| PoE Budget |
40 W |
| Installation Method |
Desktop / Wall Mount |
| Extend Distance |
Up to 250 m |
| MAC Address Table |
2K |
| Operating Temperature |
0°C to 40°C |
| Storage Temperature |
-40°C to 70°C |
| Operating Humidity |
10% to 90%, Non-Condensing |
| Storage Humidity |
5% to 90%, Non-Condensing |
| Dimensions |
99.8 × 98 × 25 mm |
| Certification |
CE, FCC and RoHS |
| Warranty |
3 Years |
Note: The TP-Link LS106LP is a 6-port 10/100Mbps unmanaged desktop switch featuring 3 × PoE+ ports and 3 × non-PoE ports. It supports IEEE 802.3af PoE with up to 15.4 W per port and a total PoE budget of 40 W, making it suitable for small IP camera, access point and VoIP deployments.
Important: The TP-Link LS106LP supports Extend Mode for up to 250 m PoE transmission, Isolation Mode for separating PoE port traffic and PoE Auto Recovery for automatically detecting and rebooting unresponsive PoE devices. Its fanless design provides quiet and maintenance-free operation for desktop and surveillance installations.
