| Features |
Description |
| Product Type |
USB 3.0 to Gigabit Ethernet Network Adapter |
| Host Interface |
1 × USB 3.0 |
| Ethernet Port |
1 × 10/100/1000Mbps RJ45 |
| Network Speed |
Up to 1000Mbps |
| Chipset |
AX88179 |
| Design |
Foldable and Portable |
| LED Indicator |
Network Status LED |
| Plug and Play |
Supported |
| HARDWARE |
| Input Interface |
1 × USB 3.0 |
| Output Interface |
1 × 10/100/1000Mbps RJ45 Ethernet Port |
| Chipset |
AX88179 |
| LED Indicator |
Network Status |
| Dimensions |
71 × 26 × 16.2mm |
| Weight |
20g |
| NETWORK |
| Ethernet Interface |
1 × 10/100/1000Mbps RJ45 |
| Ethernet Speed |
10/100/1000Mbps |
| Maximum Network Speed |
Up to 1000Mbps |
| Connection Type |
Wired Ethernet |
| USB |
| USB Interface |
USB 3.0 |
| USB Transfer Standard |
USB 3.0 |
| Backward Compatibility |
USB 2.0 / USB 1.1 |
| COMPATIBILITY |
| Nintendo Switch |
Supported |
| Windows |
Windows 11 / 10 / 8.1 / 8 / 7 |
| macOS |
Supported |
| Linux |
Supported |
| FEATURES |
| Plug and Play |
Supported |
| Driver Installation |
Not required for supported Plug and Play systems |
| Foldable Design |
Supported |
| Portable Design |
Supported |
| PHYSICAL |
| Dimensions |
71 × 26 × 16.2mm |
| Weight |
20g |
| Design |
Foldable and Lightweight |
| ENVIRONMENT |
| Operating Temperature |
0°C to 40°C |
| Storage Temperature |
-40°C to 70°C |
| Operating Humidity |
10%–90% RH, Non-Condensing |
| Storage Humidity |
5%–90% RH, Non-Condensing |
| CERTIFICATIONS |
| Certifications |
CE / FCC / RoHS |
Note: The TP-Link UE306 is a USB 3.0 to Gigabit Ethernet Network Adapter that adds a 10/100/1000Mbps RJ45 Ethernet port to computers and other USB devices. It uses a USB 3.0 interface and AX88179 chipset to provide wired network speeds of up to 1000Mbps. The adapter features a compact, lightweight and foldable design weighing approximately 20g. It supports Nintendo Switch, Windows 11/10/8.1/8/7, macOS and Linux OS.
Important: The UE306 is a USB 3.0 to Gigabit Ethernet Network Adapter featuring 1 × USB 3.0 interface and 1 × 10/100/1000Mbps RJ45 Gigabit Ethernet port. It supports wired network speeds of up to 1000Mbps and uses the AX88179 chipset. The adapter supports Nintendo Switch, Windows 11/10/8.1/8/7, macOS and Linux OS, with a compact foldable and lightweight 20g design.
