| Category |
Type |
Parameters |
| System |
Operating system |
linux |
| Number of online users |
4 users watch online at the same time |
| App |
O-KAM |
| Collection |
Processor |
T31 |
| Memory |
8M |
| Image Sensor |
GC2083, 1/3 CMOS (Pixel selectable, PCB compatible) |
| Minimum illumination |
0.3 ~ 0.5Lux (Color mode), 0Lux (B&W mode) |
| Lens |
4G lens, IR CUT integrated, standard lens diameter 10mm |
| Viewing angle |
D135° diagonal |
| Video |
Night vision |
Black and white night vision, photosensitive automatic recognition of light switching, 8 940nm non- luminous patch infrared lights, Illumination distance : 3 to 5 meters |
| Compression standard |
H.264+ /H.264 /MJPEF/JPEG |
| Multi-stream |
Main stream: 1080P/ 15fps Sub-stream: 360P/ 15fps |
| Bit rate |
CBR/VBR two rate control modes, and the output rate range is 128 ~ 4096kbps |
| Image adjustment |
Brightness, contrast, tilt, pan adjustable, OSD display |
| Audio |
Input |
Built-in -38dB microphone |
| Output |
Built-in 8Ω1W speaker |
| Sampling frequency/bit width |
8KHz/ 16bit |
| Compression standard/code rate |
G711A |
| AI |
Humanoid detection |
Humanoid detection, filtering invalid video content |
| Smart notification sound |
Different devices push sound difference, know exactly which device is triggered |
| Smart alarm sound |
Set different equipment alarm sounds according to different scenarios |
| More AI functions are in beta |
Pets, Vehicles, Packages, etc. |
| Network |
Wireless connection |
Scan the QR code of the device to add/Scan the QR code of the App |
| China Cat 1 |
FDD:B1/B3/B5/B8 |
| TDD:B34/B38/B39/B40/B41 |
| Overseas Cat4 |
EU LTE |
| Key |
Toggle button 1 |
ON/OFF |
| Toggle button 2 |
Mode switching (4G networking mode and DV local recording mode switching) |
| Reset button |
Long press to restore factory settings |
| Storage |
External TF card |
Support T-Flash card (up to 256GB) |
| Cloud Storage |
3 days free Cloud Storage |
| Alarm |
Alarm detection |
Support Humanoid & Motion detection, PIR detection |
| Physical indicators |
Rated voltage |
DC5V±5% |
| Powered by |
Powered by 3000mAh battery |
| Power consumption |
Sleep standby current 5mA, Work current: 400-600mA |
| Working environment |
Working temperature: – 10 ~ 55℃, Working humidity <90% |
| Weight |
(Note: in kind prevailed) |
| Size |
56×43×44mm, L*W*H |
| Packing list |
Camera*1, Bracket*1, MICRO USB*1, Manual*1, SIM Card*1 |
