Specifications Tiandy TC-R3105
| Features | Specifications |
|---|---|
| Model | TC-R3105 Spec:I/B/P/V3.0 |
| Type | 5-Channel 1-HDD PoE NVR |
| IP Camera Input | Up to 5 channels |
| Maximum Resolution | Up to 6MP |
| Incoming Bandwidth | 60Mbps |
| Outgoing Bandwidth | 40Mbps |
| Video Compression | S+265, H.265, H.264 |
Video & Audio
| Item | Specifications |
|---|---|
| Recording Resolution | 6MP, 5MP, 4MP, 3MP, 1080P, UXGA, 720P, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF |
| Preview Decoding | 1×6MP, 1×5MP, 1×4MP, 1×3MP, 4×1080P, 5×720P, 5×4CIF |
| Playback Decoding | 1×6MP, 1×5MP, 1×4MP, 1×3MP, 4×1080P, 8×720P |
| Synchronous Playback | Up to 8 channels |
| HDMI Output | 1× HDMI, up to 3840×2160 |
| VGA Output | 1× VGA, up to 1920×1080 |
| Audio Input | 1× 3.5mm two-way audio input |
| Audio Output | 1× RCA |
Storage
| Item | Specifications |
|---|---|
| SATA Interface | 1× SATA |
| HDD Capacity | Up to 10TB |
| eSATA | Not Supported |
| Recording Encryption | Supported |
| Backup | USB and network backup |
Network & PoE
| Item | Specifications |
|---|---|
| Network Interface | 1× RJ45 10/100Mbps Self-Adaptive Ethernet |
| PoE Ports | 4× RJ45 10/100Mbps |
| PoE Standard | IEEE 802.3af |
| PoE Power per Port | Up to 30W |
| Maximum PoE Current | 600mA per port |
| Network Protocols | TCP/IP, ICMP, HTTP, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, QoS, IPv4, IPv6, Multicast, ARP, UDP, SSL, Telnet, RTMP, NFS |
| ONVIF | Profile S/T/G |
| Third-Party Camera | Supported via ONVIF and RTSP |
| P2P | Supported |
Alarm & Intelligent Functions
| Function | Specifications |
|---|---|
| Alarm Input | 0 |
| Alarm Output | 1 |
| VCA | Supported |
| Motion Detection | Supported |
| Smart IP Camera | Supports recording, playback and backup of VCA alarms |
| Smart Search | Supported |
Interface
| Item | Specifications |
|---|---|
| USB | 2× USB 2.0 |
| Serial Interface | Not Supported |
| HDMI | 1× HDMI |
| VGA | 1× VGA |
| Audio Input | 1× 3.5mm |
| Audio Output | 1× RCA |
General
| Item | Specifications |
|---|---|
| Web Version | Web6 |
| Power Supply | DC48V |
| Power Consumption | 20W without HDD |
| Operating Temperature | -10°C ~ 55°C |
| Operating Humidity | 10% ~ 90% RH |
| Chassis | 1U |
| Dimensions | 44 × 255 × 231mm |
| Net Weight | Approx. 0.59kg without HDD |
Note: The TC-R3105 Spec:I/B/P/V3.0 supports up to 5 IP cameras, 4 PoE ports, 6MP recording resolution and one SATA HDD.
Important: Specifications are based on Tiandy TC-R3105 Spec:I/B/P/V3.0. Actual specifications may vary depending on hardware and firmware version.
