Specifications Dahua HAC-HFW1500TLP-A
| Features | Description |
|---|---|
| Device Type | 5MP Starlight HDCVI Fixed-Focal Bullet Camera |
| Brand / Series | Dahua / Lite Series (Cost-Effective High-Definition Surveillance) |
| Image Sensor | 1/2.7″ Progressive Scan CMOS |
| Maximum Resolution | 5MP (2880 × 1620) @ 25 fps (16:9 video output) |
| Lens Specifications | 3.6 mm fixed focal lens (2.8 mm, 6 mm, 8 mm optional) |
| Field of View | (2.8mm) Diagonal: 132° | Horizontal: 111° | Vertical: 58° (3.6mm) Diagonal: 109° | Horizontal: 92° | Vertical: 48° |
| Minimum Illumination | 0.005 Lux @ F1.6 (AGC ON), 0 Lux with IR on |
| Night Vision Range | Smart IR Illumination up to 80 meters (262 feet) |
| Protection Rating | IP67 Weatherproof Housing |
| VIDEO & INTERFACE PERFORMANCE | |
|---|---|
| Video Output Options | Switchable via OSD menu: 4-in-1 video output (CVI / TVI / AHD / CVBS analog standards) |
| Image Enhancements | DWDR (Digital Wide Dynamic Range), 2D NR, BLC, HLC, Auto White Balance |
| Audio Interface | Built-In Microphone (-A model suffix indicates integrated audio capture over coaxial cable) |
| Transmission Distance | Long-distance transmission over coaxial cable (up to 700m for 5MP via 75-3 coaxial cable) |
| POWER & PHYSICAL SPECIFICATIONS | |
|---|---|
| Power Supply | 12V DC ± 30% (Wide voltage tolerance to prevent drops over long cable runs) |
| Power Consumption | Max 5.2 W (12V DC, IR on) |
| Dimensions & Weight | 198.9 mm × 80.2 mm × 76.2 mm (7.83″ × 3.16″ × 3.00″) | Approx. 0.27 kg (Net) / 0.46 kg (Gross) |
| Operating Environment | -40°C to +60°C (-40°F to +140°F); Humidity: <95% (non-condensing) |
Note: The Dahua HAC-HFW1500TLP-A is an economic yet powerful 5MP Starlight HDCVI bullet camera featuring a hybrid plastic-metal body design (metal front cover with a plastic main body and bracket). It delivers high-resolution 16:9 video monitoring, robust Smart IR illumination up to 80 meters, and clear audio capture over coaxial cable.
Important: This camera outputs crisp 5MP high-definition resolution (2880 × 1620) over traditional coaxial cabling. It features Smart IR night vision up to 80 meters, an integrated built-in microphone (-A) for audio recording over coax, 4-in-1 switchable video outputs (CVI/TVI/AHD/CVBS), and a wide operating temperature range from -40°C to +60°C.
