| Features |
Description |
| Product Type |
4MP Smart Dual Light Fixed-focal Bullet WizSense Network Camera |
| Image Sensor |
1/2.9″ CMOS |
| Max. Resolution |
2688 × 1520 |
| Lens |
Fixed-focal 2.8mm / 3.6mm, M12, F1.6 |
| Illumination |
Smart Dual Light, IR + Warm Light up to 30m |
| AI Function |
SMD Plus, Human and Vehicle Classification, IVS |
| Audio |
Built-in Microphone |
| Storage |
MicroSD up to 256GB |
| Protection |
IP67 |
| CAMERA |
| Image Sensor |
1/2.9″ CMOS |
| Scanning System |
Progressive |
| Max. Resolution |
2688 × 1520 |
| ROM / RAM |
128MB / 128MB |
| Electronic Shutter |
Auto / Manual, 1/3s–1/100000s |
| Min. Illumination |
0.006 lux @ F1.6 (Color); 0.0006 lux @ F1.6 (B/W); 0 lux with illuminator |
| S/N Ratio |
>56dB |
| Day/Night |
Auto (ICR) / Color / B/W |
| WDR |
120dB |
| Noise Reduction |
3D NR |
| White Balance |
Auto / Natural / Street Lamp / Outdoor / Manual / Regional Custom |
| LENS |
| Lens Type |
Fixed-focal |
| Lens Mount |
M12 |
| Focal Length |
2.8mm / 3.6mm |
| Max. Aperture |
F1.6 |
| Field of View |
2.8mm: H 95° / V 52° / D 114°
3.6mm: H 78° / V 41° / D 94° |
| Close Focus Distance |
2.8mm: 0.9m; 3.6mm: 1.6m |
| DORI |
2.8mm: Detect 63.6m / Observe 25.4m / Recognize 12.7m / Identify 6.4m
3.6mm: Detect 85.4m / Observe 34.2m / Recognize 17.1m / Identify 8.5m |
| SMART DUAL LIGHT |
| Illumination Type |
IR Light + Warm Light |
| IR Distance |
Up to 30m |
| Warm Light Distance |
Up to 30m |
| Illuminators |
1 × IR LED + 1 × Warm Light |
| Illuminator Control |
Auto / Manual |
| Smart Illumination |
Supported |
| VIDEO |
| Main Stream |
2688 × 1520 @ 1–20fps; 2560 × 1440 @ 1–25/30fps |
| Sub Stream |
704 × 576 @ 1–25fps; 704 × 480 @ 1–30fps |
| Video Compression |
H.264H / H.265 / H.264 / H.264B / MJPEG |
| Smart Codec |
Smart H.265+ / Smart H.264+ |
| Bit Rate |
H.264: 32Kbps–6144Kbps; H.265: 12Kbps–6144Kbps |
| Bit Rate Control |
CBR / VBR |
| ROI |
Supported, up to 4 areas |
| Image Rotation |
0° / 90° / 180° / 270° |
| Privacy Mask |
Up to 4 areas |
| AI & INTELLIGENCE |
| SMD Plus |
Supported |
| Human Detection |
Supported |
| Vehicle Detection |
Supported |
| IVS |
Intrusion and Tripwire |
| AI Classification |
Human and Vehicle Classification |
| Smart Search |
Supported with compatible Smart NVR |
| Motion Detection |
4 areas |
| AUDIO |
| Microphone |
Built-in Microphone |
| Audio Compression |
G.711a / G.711Mu / PCM / G.726 |
| Audio Recording |
Supported |
| NETWORK & STORAGE |
| Network Interface |
1 × RJ-45 10/100 Base-T |
| Network Protocols |
IPv4 / IPv6 / HTTP / HTTPS / TCP / UDP / ARP / RTP / RTSP / RTCP / RTMP / SMTP / FTP / SFTP / DHCP / DNS / DDNS / NTP / Multicast / ICMP / IGMP |
| Interoperability |
ONVIF Profile S / Profile T / CGI / P2P / Milestone |
| Users |
Up to 6 users |
| Bandwidth |
Up to 36Mbps total |
| MicroSD |
Up to 256GB |
| Network Storage |
FTP / SFTP |
| Management Software |
DSS / DMSS |
| Cybersecurity |
HTTPS / 802.1X / IP-MAC Filtering / Video Encryption / Account Lockout / Security Logs |
| INTERFACE & POWER |
| Network Port |
1 × RJ-45 10/100 Base-T |
| Power Supply |
12V DC / PoE (802.3af) |
| Power Consumption |
Basic: 2.1W (12V DC) / 2.5W (PoE)
Max.: 4.4W (12V DC) / 5.2W (PoE) |
| PHYSICAL & ENVIRONMENT |
| Casing Material |
Metal |
| Dimensions |
166.2 × 70 × 70mm |
| Net Weight |
0.48kg |
| Operating Temperature |
-40°C to +60°C |
| Operating Humidity |
≤95% RH |
| Storage Temperature |
-40°C to +60°C |
| Protection |
IP67 |
| Mounting |
Wall / Ceiling / Pole Mount |
Note: The DH-IPC-HFW2449S-S-IL combines 4MP imaging with Smart Dual Light, SMD Plus and AI-based human and vehicle classification.
Important: The camera supports both 12V DC and IEEE 802.3af PoE. Smart Dual Light can switch between IR and warm light according to the configured illumination mode.
