Specifications Hikvision DS-2CD2143G2-LIS2U
| Features | Description |
|---|---|
| Device Type | 4 MP Smart Hybrid Light Fixed Dome Network Camera |
| Brand / Series | Hikvision / Pro Series (EasyIP) with AcuSense Technology |
| Image Sensor | 1/3″ Progressive Scan CMOS |
| Lens | Fixed Focal Lens (Options: 2.8 mm or 4 mm) |
| Max. Resolution | 4 Megapixel (2688 × 1520) @ 30/25 fps |
| Illuminator Type | Smart Hybrid Light (Infrared & White Light modes) |
| Illumination Range | Up to 30 m (98 ft) for both IR and White Light |
| Audio Features | Built-in Dual-Microphone and Audio I/O (S-model integration) |
| Video Compression | H.265+, H.265, H.264+, H.264 |
| Protection Standards | IP67 (Water and Dust Resistant) and IK10 (Vandal-Proof) |
| Min. Illumination | Color: 0.005 Lux @ (F1.6, AGC ON), 0 Lux with Light ON |
|---|---|
| Interface Options | 1 RJ45 10M/100M port, Alarm I/O (1 in, 1 out), Audio I/O (1 in, 1 out), Built-in MicroSD slot (up to 512 GB) |
| Image Settings & Enhancement | 120 dB True WDR, 3D DNR, BLC, HLC, ROI (1 fixed region) |
| Power Supply & Consumption | 12 VDC ± 25% (Max. 6.5 W) or PoE (IEEE 802.3af, Class 3, Max. 8 W) |
| SMART FEATURES | |
|---|---|
| Smart Hybrid Light | Flexibly switch between three lighting modes: IR mode for discreet night vision, White Light mode for full-color recording, or Smart mode (switches from IR to White Light when a target is detected) |
| AcuSense Deep Learning | Focuses firmly on human and vehicle classification, drastically minimizing false alarms caused by moving trees, animals, or heavy rain |
| Built-in Dual-Mic (2U) | Integrated dual-microphone array enhances audio pickup range and employs advanced noise cancellation for clear, high-quality audio security |
| Robust Dome Housing | Engineered with an IK10 vandal-resistant dome cover and IP67 weather-proofing, making it perfect for exposed public or commercial spaces |
| GENERAL | |
|---|---|
| Dimensions & Weight | Ø 121.4 mm × 92.2 mm (Ø 4.8″ × 3.6″), Approx. 550 g (1.2 lb) |
| Operating Conditions | -30°C to 60°C (-22°F to 140°F), Humidity 95% or less (non-condensing) |
| Warranty | Standard Manufacturer Warranty (Typically 3 Years through Authorized Distributors) |
Note: The Hikvision DS-2CD2143G2-LIS2U is a highly capable 4MP dome camera that combines AcuSense target classification with Smart Hybrid Light technology. The “LIS2U” designation denotes its rich feature set: Smart Light (L), Infrared (I), Alarm/Audio interfaces (S), and a built-in dual microphone (2U).
Important: By utilizing Smart Hybrid Light mode, this camera remains inconspicuous with IR night vision during idle periods but instantly triggers full-color illumination when a human or vehicle approaches, capturing critical identifying details while acting as a visual deterrent.
