Specifications

Camera
• Image Sensor2 megapixel progressive scan CMOS
• Max. Resolution1920 (H) × 1080 (V)
• Min. IlluminationColor 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR
• Shutter Time1/25 (1/30) s to 1/50,000 s
• Day & NightIR cut filter
• Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360°
• Signal SystemPAL/NTSC

Lens
• Lens Type2.8 mm, 3.6 mm, 6 mm fixed lens
• Focal Length & FOV103° (2.8 mm), 82.2° (3.6 mm), 54° (6 mm)
• Lens MountM12

• Image Parameters SwitchSTD/HIGH-SAT
• Image SettingsBrightness, Sharpness, DNR, Mirror
• Frame RatePAL: 1080p@25fps NTSC: 1080p@30fps
• Day/Night ModeSmart/color/BW(Black and White)
• AGCLow/middle/high

Interface
• Video OutputSwitchable TVI/AHD/CVI/CVBS

General
• MaterialMetal
• DimensionØ 70 mm × 154.5 mm (Ø 2.76″ × 6.08″)
• Approx. 310 g (0.68 lb.)
• Operating Condition‘-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
• CommunicationHIKVISION-C
• LanguageEnglish
• Power Supply12 VDC ±15%
• ConsumptionMax. 3.8 W
• IR RangeUp to 30 m

Approval
• ProtectionIP66
