| Features |
Description |
| Product Type |
100 Mbps Long-Range Unmanaged PoE Switch |
| Layer |
Layer 2 |
| Management |
Unmanaged |
| Total Ports |
26 Ports |
| PoE Ports |
24 × 10/100 Mbps RJ45 PoE Ports |
| Uplink Ports |
2 × Gigabit Combo Ports |
| Switching Capacity |
8.80 Gbps |
| Forwarding Rate |
6.55 Mpps |
| MAC Address Table |
16K |
| Internal Cache |
4 Mbits |
| Forwarding Mode |
Store-and-Forward |
| PoE |
Description |
| PoE Standard |
IEEE 802.3af / IEEE 802.3at |
| PoE Ports |
Ports 1–24 |
| Maximum Power per Port |
30 W |
| PoE Power Budget |
370 W |
| Long-Range PoE |
Ports 17–24: Up to 300 m |
| PoE Watchdog |
Automatically Detects and Restarts Unresponsive Cameras |
| Network Functions |
Description |
| Port Isolation |
Supported on Ports 1–24 |
| VIP Ports |
Ports 1–8 |
| Long Range Mode |
Ports 17–24, Up to 300 m |
| Flow Control |
IEEE 802.3x Full Duplex |
| General |
Description |
| Power Supply |
100–240 V AC, 50/60 Hz, Max. 6.5 A |
| Maximum Power Consumption |
400 W |
| Idle Power Consumption |
30 W |
| Surge Protection |
6 kV |
| Installation |
Rack Mount |
| Material |
Metal |
| Operating Temperature |
0°C to 45°C |
| Storage Temperature |
-40°C to 85°C |
| Operating Humidity |
5%–95%, Non-Condensing |
| Dimension |
440 × 44 × 220.8 mm |
| Net Weight |
2.785 kg |
| Gross Weight |
3.54 kg |
Note: The Hikvision DS-3E0326P-E(C) is a 26-port Layer 2 unmanaged PoE switch featuring 24 × 10/100 Mbps PoE ports and 2 × Gigabit Combo uplink ports. It supports IEEE 802.3af/at, up to 30 W per PoE port, a 370 W total PoE budget, up to 300 m long-range PoE transmission on ports 17–24, PoE watchdog, port isolation, and 6 kV surge protection. It is suitable for CCTV surveillance and other PoE network applications.
