| Features |
Specifications |
| Model |
CS-H5-R201-1H3KFL4GA |
| Product Type |
2K 4G Smart Home Camera |
| Image Sensor |
1/2.8″ Progressive Scan CMOS |
| Resolution |
2304 × 1296 (2K) |
| Lens |
4mm @ F1.6 / 6mm @ F1.6 |
| Night Vision |
IR Night Vision up to 30 m |
| Connectivity |
4G LTE and RJ45 Ethernet |
| Weatherproof |
IP67 |
Camera & Lens
| Features |
Specifications |
| Image Sensor |
1/2.8″ Progressive Scan CMOS |
| Shutter Speed |
Self-adaptive shutter |
| Lens |
4mm @ F1.6; 6mm @ F1.6 |
| 4mm Lens Viewing Angle |
Diagonal 102°, Horizontal 86°, Vertical 46° |
| 6mm Lens Viewing Angle |
Diagonal 62°, Horizontal 52°, Vertical 28° |
| Lens Mount |
M12 |
| Minimum Illumination |
0.01 Lux @ (F1.6, AGC ON); 0 Lux with IR |
| Day / Night Switch |
IR-Cut filter with auto-switching |
| Digital Noise Reduction |
3D DNR |
| Wide Dynamic Range |
Digital WDR |
| Backlight Compensation |
Supported |
| IR Night Vision Distance |
Up to 30 m / 98 ft |
Video & Audio
| Features |
Specifications |
| Max Resolution |
2304 × 1296 (2K) |
| Frame Rate |
Self-adaptive during network transmission |
| Video Compression |
H.265 / H.264 |
| H.265 Type |
Main Profile |
| Video Bit Rate |
Ultra-HD, Hi-Def and Standard; Adaptive Bit Rate |
| Audio Bit Rate |
Self-adaptive |
| Two-Way Talk |
Supported |
Night Vision & Active Defense
| Features |
Specifications |
| Color Night Vision |
Supported with built-in spotlights |
| Black & White Night Vision |
Supported with infrared illumination |
| Smart Night Vision |
Automatically illuminates the environment when human motion is detected |
| Active Defense |
Siren and strobe light |
| Spotlight |
Dual built-in spotlights |
| Alarm Settings |
Adjustable sound and light alarm settings |
Smart Features
| Features |
Specifications |
| AI Detection |
AI-powered human shape detection and vehicle shape detection |
| Human Motion Detection |
Supported |
| Vehicle Detection |
Supported |
| Customized Alert Area |
Supported |
| Two-Way Talk |
Supported |
| General Functions |
Anti-flicker, dual-stream, heartbeat, password protection and watermark |
Network & Connectivity
| Features |
Specifications |
| 4G Network |
4G LTE Connectivity |
| SIM Card |
Nano SIM Card |
| Wi-Fi |
Not Supported |
| Wired Network |
RJ45 × 1 (10M / 100M Adaptive Ethernet Port) |
| Network Connection |
4G LTE or Wired Ethernet |
| Frequency Bands |
IN LTE-FDD: B1/B3/B5/B8; IN LTE-TDD: B34/B38/B39/B40/B41 |
| EU LTE-FDD |
B1/B3/B5/B7/B8/B20/B28 |
| LA LTE-FDD |
B2/B3/B4/B5/B7/B8/B28/B66 |
Storage
| Features |
Specifications |
| Local Storage |
Supports MicroSD Card up to 512 GB |
| Cloud Storage |
EZVIZ CloudPlay Storage (Subscription Required) |
General Specifications
| Features |
Specifications |
| Operating Temperature |
-30°C to 50°C (-22°F to 122°F) |
| Operating Humidity |
95% or less (non-condensing) |
| Protection |
IP67 |
| Power Supply |
DC 12V/1A |
| Power Consumption |
Maximum 7W |
| Dimensions |
183 × 93 × 75 mm |
| Packaging Dimensions |
256 × 197 × 118 mm |
| Net Weight |
482 g |
| Weight with Package |
856 g |
| Certifications |
CE / WEEE / RoHS / REACH |
In the Box
| Features |
Specifications |
| Camera |
H5 4G Camera |
| Mounting Bracket |
Included |
| Drill Template |
Included |
| Power Adapter |
Included |
| Waterproof Kit |
Included |
| Bracket Screw Kit |
Included |
| Documentation |
Regulatory Information and Quick Start Guide |
Note: The EZVIZ H5 4G is a 2K outdoor security camera supporting 4G LTE connectivity, AI human and vehicle detection, color night vision, two-way talk and MicroSD card storage up to 512 GB.
Important: The H5 4G does not support Wi-Fi. A Nano SIM card with a suitable cellular data plan or a wired Ethernet connection is required. Check the network coverage and power supply requirements before installation.
