Display Parameters

• Size/
• Operation Method/
• Type/

Video Parameters

• Supplement Light

  IR supplement

• Lens1
• FOV

  Horizontal: 129° Vertical: 75°

• Pixel

  Main stream : 1920 × 1080

  Sub stream : 720 × 480

Audio Parameters

• Audio QualityNoise suppression and echo cancellation

Network Parameters

• Communication Protocol

  TCP/IP, RTSP

• Wired Network10/100 Mbps self-adaptive Ethernet
• Wi-Fi/
• Bluetooth/
• Device Interfaces
• Network Interface1
• Exit Button2
• Lock Control2
• Door Contact Input2
• Power Interface1

General

• Button1 button
• InstallationSurface mounting
• Indicator3
• 385 g
• Protective LevelIP65, IK08
• Power Supply Method

  IEEE802.3af, standard PoE 12 VDC

• Working Temperature-40° C to +55° C(-40° F to 131° F)
• Working Humidity10% to 95%
• Dimensions174 mm × 91 mm × 29 mm
• Battery/
• Application EnvironmentOutdoor
• Power Consumption

  ＜ 10 W
