Specifications Dahua IPC-HFW1435SP-W-S2
| Features | Description |
|---|---|
| Device Type | 4MP IR Wi-Fi Bullet Network Camera (Series 2) |
| Brand / Series | Dahua / Entry Series (Wireless Video Surveillance) |
| Image Sensor | 1/3″ 4Megapixel Progressive CMOS |
| Maximum Resolution | 4MP (2560 × 1440) @ 20 fps (Supports 3M / 1080p @ 25/30 fps) |
| Lens Specifications | 2.8 mm or 3.6 mm fixed focal lens options |
| Field of View | (2.8mm) Horizontal: 97° | Vertical: 52° | Diagonal: 116° (3.6mm) Horizontal: 76° | Vertical: 42° | Diagonal: 90° |
| Minimum Illumination | Color: 0.9343 Lux @ F2.0; 0 Lux with IR on |
| Night Vision Range | Smart IR Illumination up to 30 meters (98 feet) |
| Protection Rating | IP67 Weatherproof Housing |
| VIDEO, AUDIO & NETWORK CAPABILITIES | |
|---|---|
| Video Compression | H.265 / H.264 / H.264H / H.264B / MJPEG dual-stream encoding |
| Wireless Protocol | Wi-Fi Support (IEEE802.11b/g/n, 2.4 GHz range) alongside a wired RJ-45 (10/100 Base-T) port |
| Image Enhancements | DWDR, 3D DNR, HLC, BLC, Digital Watermarking |
| Smart Features | Motion Detection (4 rectangular areas), Region of Interest (RoI) |
| STORAGE & SYSTEM INTERFACES | |
|---|---|
| Edge Storage | MicroSD Card Slot supporting up to 256 GB local storage |
| Interoperability | ONVIF (Profile S/T/G), CGI, P2P (DMSS app support) |
| Management Software | Smart PSS, DMSS, Web UI |
| Browser Support | IE, Chrome, Firefox (plug-in free versions supported) |
| POWER & PHYSICAL SPECIFICATIONS | |
|---|---|
| Power Supply | 12V DC ± 30% power adapter |
| Power Consumption | Max. 5.39 W (IR full intensity active) |
| Dimensions & Weight | 164.9 mm × 70 mm × 125.2 mm (6.5″ × 2.8″ × 4.9″) | Net Weight: Approx. 0.43 kg (0.95 lb) |
| Operating Environment | -30°C to +50°C (-22°F to +122°F); Humidity: Less than 95% RH |
Note: The Dahua IPC-HFW1435SP-W-S2 is a dependable 4MP outdoor bullet network camera featuring native Wi-Fi connectivity for simplified placement without a direct physical cable run. Equipped with clear 2K resolution, 30m infrared night vision, a rugged IP67 metal enclosure, and flexible local or remote storage, it serves as an efficient solution for residential or small-business wireless monitoring.
Important: This wireless camera operates on a 2.4 GHz Wi-Fi network (or via a hardwired Ethernet cable) and outputs up to 4MP resolution at 20 fps. It includes a MicroSD card slot supporting up to 256 GB, features an IP67 metal weatherproof casing, runs on a standard 12V DC power supply, and functions smoothly in temperatures ranging from -30°C to +50°C.
