Specifications Uniview IPC2122LB-SF28-A
| Features | Description |
|---|---|
| Device Type | 2MP Fixed IR Bullet Network Camera |
| Brand / Series | Uniview (UNV) / Prime Series (B Series) |
| Image Sensor | 1/2.7″ Progressive Scan 2.0 Megapixel CMOS |
| Maximum Resolution | 1080P (1920 × 1080) @ 30/25 fps |
| Lens Specifications | 2.8 mm Fixed Focal Lens (F2.0) |
| Field of View | Horizontal: 112.9° | Vertical: 59.1° | Diagonal: 141.2° |
| Minimum Illumination | Color: 0.01 Lux (F2.0, AGC ON); 0 Lux with IR active |
| Night Vision Range | Smart IR illumination up to 30 meters (98 feet) |
| Protection Rating | IP67 Weatherproof Metal & Plastic Housing |
| VIDEO & NETWORK PERFORMANCE | |
|---|---|
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| Wide Dynamic Range | Digital WDR (DWDR) for balanced lighting exposure |
| Corridor Mode | Supports 9:16 vertical corridor viewing format |
| Network Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, QoS |
| SMART FEATURES & INTERFACES | |
|---|---|
| Smart Analytics | Motion detection, human body detection (smart intrusion / motion alerting) |
| Edge Storage | Not supported (relies on NVR/VMS or cloud recording) |
| Integration Support | ONVIF (Profile S, Profile T), API |
| Network Interface | 1 × RJ45 10M/100M Base-TX Ethernet port |
| POWER & PHYSICAL SPECIFICATIONS | |
|---|---|
| Power Supply | DC 12V ± 25% or Power over Ethernet (PoE IEEE 802.3af) |
| Power Consumption | Max 4.0 W (PoE: Max 5.0 W) |
| Dimensions & Weight | 161 × 63 × 62 mm (6.3″ × 2.5″ × 2.4″) | Approx. 0.23 kg (0.51 lbs) |
| Operating Environment | -30°C to 60°C (-22°F to 140°F); Humidity: ≤95% RH (non-condensing) |
Note: The Uniview IPC2122LB-SF28-A is an entry-level 2MP fixed bullet network camera designed for cost-effective, reliable video surveillance. It delivers sharp Full HD 1080P imagery using a wide-angle 2.8mm lens, features smart IR night vision up to 30 meters, and utilizes Ultra 265 compression to maximize bandwidth and storage efficiency.
Important: The camera features a 2.8mm fixed lens with an ultra-wide 112.9° horizontal field of view. It supports Smart IR up to 30 meters, operates on either 12V DC or PoE (802.3af), and is housed in an IP67-rated weatherproof enclosure built to perform reliably in demanding outdoor environments ranging from -30°C to 60°C.
