| Features |
Description |
| Device Type |
4MP ColorHunter Fixed Dual-light Turret Network Camera |
| Image Sensor |
1/3.0″ Progressive Scan CMOS |
| Maximum Resolution |
2688 × 1520 |
| Lens |
2.8mm Fixed Lens |
| WDR |
120dB True WDR |
| IR Range |
Up to 30m |
| White Light Range |
Up to 30m |
| Video Compression |
Ultra 265 / H.265 / H.264 / MJPEG |
| Smart Features |
Cross Line, Intrusion, Motion Detection, Ultra Motion Detection, Tampering Alarm and Audio Detection |
| Audio |
Built-in Microphone and Speaker, Two-way Audio |
| Storage |
MicroSD up to 512GB |
| Protection |
IP67 |
| CAMERA |
| Image Sensor |
1/3.0″, 4.0 Megapixel Progressive Scan CMOS |
| Minimum Illumination |
Color: 0.003 Lux (F1.6, AGC ON), 0 Lux with Light |
| Day/Night |
IR-Cut Filter with Auto Switch (ICR) |
| Shutter |
Auto / Manual, 1 ~ 1/100000s |
| Adjustment Angle |
Pan: 0° ~ 360°, Tilt: 0° ~ 80°, Rotate: 0° ~ 360° |
| WDR |
120dB |
| S/N |
>52dB |
| LENS |
| Lens Type |
2.8mm @F1.6 Fixed Lens |
| Focal Length |
2.8mm |
| Iris |
Fixed, F1.6 |
| Horizontal Field of View |
97.0° |
| Vertical Field of View |
52.2° |
| Diagonal Field of View |
107.5° |
| DORI |
| Detect |
63.0m |
| Observe |
25.2m |
| Recognize |
12.6m |
| Identify |
6.3m |
| VIDEO |
| Video Compression |
Ultra 265 / H.265 / H.264 / MJPEG |
| Main Stream |
4MP (2688 × 1520), Max 25fps; 4MP (2560 × 1440), Max 25fps; 3MP (2304 × 1296), Max 30fps; 1080P (1920 × 1080), Max 30fps; 720P (1280 × 720), Max 30fps |
| Sub Stream |
720P (1280 × 720), D1 (720 × 576), 640 × 360, Max 30fps |
| Video Bit Rate |
128Kbps ~ 16Mbps |
| Video Stream |
Dual Streams |
| H.264 Profile |
Baseline Profile / Main Profile / High Profile |
| U-Code |
Supported |
| ROI |
Up to 8 Areas |
| OSD |
Up to 4 OSDs |
| Privacy Mask |
Up to 4 Areas |
| Corridor Mode |
Supported, 9:16 |
| IMAGE |
| White Balance |
Auto / Outdoor / Fine Tune / Sodium Lamp / Locked / Auto2 |
| Digital Noise Reduction |
2D / 3D DNR |
| Smart IR |
Supported |
| Smart Illumination |
Supported |
| HLC |
Supported |
| BLC |
Supported |
| Defog |
Digital Defog |
| Image Flip |
Normal / Vertical / Horizontal / 180° / 90° Clockwise / 90° Anti-Clockwise |
| SMART FEATURES |
| Basic Detection |
Cross Line, Intrusion, Motion Detection, Ultra Motion Detection, Tampering Alarm and Audio Detection |
| Intrusion Detection |
Based on Human Body Detection |
| False Alarm Filtering |
Supported |
| ColorHunter |
Provides High Image Quality in Low-Light Environments |
| ILLUMINATOR |
| Illuminator Type |
Dual Light |
| IR Range |
Up to 30m |
| White Light Range |
Up to 30m |
| IR Wavelength |
850nm |
| Light Control |
Auto / Manual |
| STORAGE |
| Edge Storage |
MicroSD, Up to 512GB |
| Network Storage |
ANR, NAS (NFS) |
| NETWORK |
| Network Interface |
1 × RJ45 10/100Mbps Base-TX Ethernet |
| ONVIF |
Profile S / Profile G / Profile T |
| Network Protocol |
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL/TLS, SNMP and QoS |
| Compatible Integration |
ONVIF / API / SDK |
| User / Host |
Up to 32 Users, 3 User Levels |
| Video Output |
Not Supported |
| AUDIO |
| Audio Compression |
G.711U / G.711A |
| Audio Bit Rate |
64Kbps |
| Two-way Audio |
Supported |
| Sampling Rate |
8KHz |
| Suppression |
Supported |
| Built-in Microphone |
Supported |
| Built-in Speaker |
Supported |
| INTERFACE |
| Audio I/O |
N/A |
| Alarm I/O |
N/A |
| Serial Port |
N/A |
| Wi-Fi |
N/A |
| Network |
1 × RJ45 10/100Mbps Base-TX Ethernet |
| Reset Button |
Supported |
| POWER & PROTECTION |
| Power Supply |
DC 12V ±25% / PoE (IEEE 802.3af) |
| Maximum Power Consumption |
8.0W |
| Surge Protection |
4KV |
| Protection |
IP67 |
| PHYSICAL & ENVIRONMENT |
| Dimensions |
Φ118 × 96mm |
| Weight |
0.32kg |
| Material |
Metal + Plastic |
| Operating Temperature |
-30°C to 60°C |
| Storage Temperature |
-30°C to 60°C |
| Operating Humidity |
≤95% RH, Non-Condensing |
| Storage Humidity |
≤95% RH, Non-Condensing |
| Installation |
Indoor / Outdoor |
| Adjustment |
3-Axis |
Note: The Uniview IPC3614LE-ADF28KC-DL is a 4MP ColorHunter Fixed Dual-light Turret Network Camera featuring a 1/3.0″ progressive scan CMOS sensor, 2.8mm fixed lens and 120dB True WDR. It supports 4MP video up to 25fps, Ultra 265/H.265/H.264/MJPEG compression, Smart IR up to 30m, white light up to 30m, built-in microphone and speaker, two-way audio, MicroSD storage up to 512GB and 9:16 Corridor Mode. The camera supports DC 12V and PoE (IEEE 802.3af).
Important: The IPC3614LE-ADF28KC-DL is a 4MP ColorHunter Fixed Dual-light Turret Camera with 120dB True WDR, Smart IR up to 30m and White Light up to 30m. It supports built-in microphone and speaker with two-way audio, Smart Detection including Cross Line, Intrusion and Motion Detection, MicroSD storage up to 512GB, PoE (IEEE 802.3af), 4KV surge protection and IP67 protection. Maximum power consumption is 8W.
