| Features |
Description |
| Device Type |
2MP LightHunter VF Eyeball Network IR Camera |
| Image Sensor |
1/2.7″ Progressive Scan CMOS |
| Maximum Resolution |
1920 × 1080 |
| Lens |
2.7–13.5mm Motorized Varifocal Lens |
| Optical Zoom |
5X |
| WDR |
120dB True WDR |
| IR Range |
Up to 40m |
| Video Compression |
Ultra 265 / H.265 / H.264 / MJPEG |
| Smart Features |
Smart Intrusion Prevention, Cross Line, Intrusion, Enter Area and Leave Area Detection |
| People Flow Counting |
Supported |
| Crowd Density Monitoring |
Supported |
| Audio |
Audio Input / Audio Output, Built-in Microphone |
| Alarm |
1 × Alarm Input / 1 × Alarm Output |
| Storage |
MicroSD up to 256GB |
| Protection |
IP67 |
| Vandal Resistance |
IK10 |
| CAMERA |
| Image Sensor |
1/2.7″, 2.0 Megapixel Progressive Scan CMOS |
| Maximum Resolution |
1920 × 1080 |
| Minimum Illumination |
Color: 0.001 Lux (F1.35, AGC ON), 0 Lux with IR |
| Day/Night |
IR-Cut Filter with Auto Switch (ICR) |
| Shutter |
Auto / Manual, 1 ~ 1/100000s |
| WDR |
120dB True WDR |
| S/N |
>52dB |
| Adjustment Angle |
Pan: 0° ~ 360°, Tilt: 0° ~ 75°, Rotate: 0° ~ 360° |
| LENS |
| Lens Type |
Motorized Varifocal, AF Automatic Focusing |
| Focal Length |
2.7–13.5mm |
| Iris |
F1.35 |
| Horizontal Field of View |
114° ~ 31.8° |
| Vertical Field of View |
58.9° ~ 17.6° |
| Diagonal Field of View |
148.2° ~ 37.5° |
| Optical Zoom |
5X |
| DORI |
| Detect |
40.5m ~ 202.5m |
| Observe |
16.2m ~ 81m |
| Recognize |
8.1m ~ 40.5m |
| Identify |
4.1m ~ 20.3m |
| VIDEO |
| Video Compression |
Ultra 265 / H.265 / H.264 / MJPEG |
| Main Stream |
2MP (1920 × 1080), Max 30fps |
| Sub Stream |
D1 (720 × 576), Max 30fps |
| Third Stream |
CIF (352 × 288), Max 30fps |
| Video Bit Rate |
128Kbps ~ 16Mbps |
| Video Stream |
Triple Streams |
| U-Code |
Supported |
| 9:16 Corridor Mode |
Supported |
| OSD |
Up to 8 OSDs |
| Privacy Mask |
Up to 8 Areas |
| ROI |
Up to 8 Areas |
| IMAGE |
| White Balance |
Auto / Outdoor / Fine Tune / Sodium Lamp / Locked / Auto2 |
| Digital Noise Reduction |
2D / 3D DNR |
| Smart IR |
Supported |
| HLC |
Supported |
| BLC |
Supported |
| Defog |
Digital Defog |
| Image Flip |
Normal / Vertical / Horizontal / 180° / 90° Clockwise / 90° Anti-clockwise |
| SMART FEATURES |
| Smart Intrusion Prevention |
Cross Line, Intrusion, Enter Area and Leave Area Detection |
| Target Classification |
Human, Motor Vehicle and Non-Motor Vehicle |
| False Alarm Filtering |
Supported |
| People Flow Counting |
Supported |
| Crowd Density Monitoring |
Supported |
| Motion Detection |
Supported |
| ILLUMINATOR |
| Light Type |
IR |
| IR Range |
Up to 40m |
| IR Wavelength |
850nm |
| IR Control |
Auto / Manual |
| Smart IR |
Supported |
| AUDIO & ALARM |
| Audio Input |
1 Channel |
| Audio Output |
1 Channel |
| Built-in Microphone |
Supported |
| Audio Compression |
G.711 |
| Two-Way Audio |
Supported |
| Sampling Rate |
8KHz |
| Audio Suppression |
Supported |
| Alarm Input |
1 Channel |
| Alarm Output |
1 Channel |
| STORAGE |
| Edge Storage |
MicroSD, Up to 256GB |
| Network Storage |
ANR / NAS (NFS) |
| NETWORK |
| Network Interface |
1 × RJ45 10/100Mbps Base-TX Ethernet |
| ONVIF |
Profile S / Profile G / Profile T |
| Compatible Integration |
ONVIF / API |
| Network Protocols |
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP and QoS |
| Client |
EZStation / EZView / EZLive / Web Browser |
| POWER & PROTECTION |
| Power Supply |
DC 12V ±25% / PoE (IEEE 802.3af) |
| Maximum Power Consumption |
7.8W |
| Surge Protection |
6KV |
| Protection |
IP67 |
| Vandal Resistance |
IK10 |
| PHYSICAL & ENVIRONMENT |
| Dimensions |
Φ129.1 × 111.2mm |
| Weight |
0.70kg |
| Material |
Metal |
| Operating Temperature |
-30°C to 60°C |
| Storage Temperature |
-30°C to 60°C |
| Operating Humidity |
≤95% RH, Non-Condensing |
| Storage Humidity |
≤95% RH, Non-Condensing |
Note: The Uniview IPC3632SA-ADZK is a 2MP LightHunter VF Eyeball Network IR Camera featuring a 1/2.7″ progressive scan CMOS sensor, 2.7–13.5mm motorized varifocal lens, 5X optical zoom, 1920 × 1080 resolution, 120dB True WDR and LightHunter technology for high-quality imaging in low-light environments. It supports Ultra 265/H.265/H.264/MJPEG compression, Smart Intrusion Prevention, people flow counting, crowd density monitoring, built-in microphone, two-way audio, MicroSD storage up to 256GB, IP67 and IK10 protection, and PoE (IEEE 802.3af).
Important: The IPC3632SA-ADZK is a Motorized Varifocal Eyeball Camera, not a PTZ camera. Its 2.7–13.5mm motorized lens provides a 114°–31.8° horizontal field of view and DORI distances of 40.5–202.5m Detect / 4.1–20.3m Identify. IR illumination reaches up to 40m. The camera supports DC 12V or PoE (IEEE 802.3af) and has IP67 + IK10 protection.
