6 Core OS2 Armored Central Tube Fiber Optic Cable

  • 6 Core OS2 9/125μm Singlemode fiber optic cable
  • Central Tube armored design with steel tape protection
  • Single Jacket PE sheath with UV-resistant protection
  • Compact structure with enhanced mechanical protection
  • Dry water-blocking material for moisture resistance
  • Complies with ANSI/TIA-568.3, IEC 60794 and ITU-T G.652.D
หมวดหมู่: , ป้ายกำกับ:
*** ผู้รับเหมาโครงการต้องการราคาพิเศษสนใจติดต่อ ***
เบอร์มือถือ : 063-1963553 ไอดีไลน์ : ifocusshop

Specifications LINK UFC9706CM

Features Description
Device Type ADSS Multi-Tube All-Dielectric Self-Support Fiber Optic Cable
Fiber Type OS2 9/125μm Single-Mode Fiber
Core Count 6 Core
Cable Construction ADSS Multi-Tube, Single Jacket, All-Dielectric
Jacket Material UV-Resistant Black HDPE Outer Jacket
Installation Aerial and Underground Duct Installation
Water Protection Dry Water Blocking Tape and Water Blocking Yarn
Tensile Strength 1,800 N Self-Support Design
Cable Length 4,000 Meters per Drum
Application Backbone Network, FTTx, CCTV, CATV and Enterprise Fiber Infrastructure
Fiber Standard ITU-T G.652D OS2 Single-Mode
Fiber Diameter 9/125μm
Fiber Type Single-Mode Fiber (SMF)
Cable Structure ADSS Multi-Tube, Outdoor Single Jacket
Armor Type All-Dielectric (Non-Metallic)
Jacket Type Single HDPE Jacket
Strength Member Dielectric Central Strength Member with Water Blocking E-Glass Yarn
Installation Type Aerial and Underground Duct
Standards ANSI/TIA-568.3-E, ANSI/TIA-568.3-D, ANSI/ICEA 640, IEEE P-1222, Telcordia GR-20-CORE, ITU-T G.652D, ISO/IEC 11801, IEC 60793, IEC 60794-1-2, EN 50173-1, TIS 2166, RoHS
Application 40/100Gb Ethernet, 10Gb Ethernet, Gigabit Ethernet, Fiber Channel, FTTx, CATV, CCTV and Backbone Network
SMART FEATURES
All-Dielectric Design No Metallic Components, Preventing Electrical Induction and Lightning Risks
Multi-Tube Construction Color-Coded Loose Tubes Protect Fiber Cores and Improve Cable Flexibility
Self-Support Design Designed for Aerial Installation Without Additional Messenger Wire
Water Blocking System Dry Water Blocking Tape and Yarn Prevent Moisture Penetration
Outdoor HDPE Jacket UV-Resistant Jacket Provides Long-Term Weather Protection
GENERAL
Fiber Count 6 Core
Core / Cladding Size 9/125μm Single-Mode Fiber
Cable Type ADSS Multi-Tube Single Jacket
Outer Jacket Color Black
Cable Weight Approximately 80kg/km
Maximum Tensile Strength 1,800 N
Installation / Operating Temperature -40°C to +70°C
Packing 4,000m per Drum
Warranty 30 Years

Note: The LINK UFC9706CM is a 6-core OS2 9/125μm single-mode ADSS Multi-Tube fiber optic cable featuring an all-dielectric self-support construction. It uses color-coded loose tubes, dielectric central strength member, water-blocking tape and yarn, and a UV-resistant HDPE jacket to provide reliable outdoor performance for aerial and duct installations. It is suitable for backbone networks, FTTx, CCTV, CATV, and enterprise fiber infrastructure.

Important: The LINK UFC9706CM is designed for outdoor self-support deployment with a maximum tensile strength of 1,800 N. Its all-dielectric ADSS structure eliminates electrical induction risks while providing high mechanical strength, moisture protection, and long-term reliability for high-speed fiber communication networks.

จัดจำหน่าย By บริษัทโฟกัส ซิสเต็ม แอนด์ ดีไซน์ ช่างติดเเละซ้อมกล้องวงจรปิด พัทยา ชลบุรี

Datasheet
