LINK UFC9724MAD
LINK UFC9724MAD
24 Core OS2 Armored Figure 8 Fiber Optic Cable (Double Jacket)
- 24 Core OS2 9/125μm Singlemode fiber optic cable
- Figure 8 Multi-Tube armored design with stranded messenger wire
- Double Jacket PE sheath with UV protection
- Supports self-supporting aerial installation
- Steel armored construction for enhanced mechanical protection
- Complies with ANSI/TIA-568.3, IEC 60794 and ITU-T G.652.D
*** ผู้รับเหมาโครงการต้องการราคาพิเศษสนใจติดต่อ ***
เบอร์มือถือ : 063-1963553 ไอดีไลน์ : ifocusshop
Specifications LINK UFC9724MAD
| Features | Description |
|---|---|
| Device Type | ARSS Multi-Tube Armored Self-Support Fiber Optic Cable (Double Jacket) |
| Fiber Type | OS2 9/125μm Single-Mode Fiber |
| Core Count | 24 Core |
| Cable Construction | ARSS Multi-Tube, Steel Armored, Double Jacket |
| Jacket Material | Double Layer UV-Resistant Black HDPE Outer Jacket |
| Installation | Aerial, Indoor/Outdoor, Direct Burial and Underground Duct Installation |
| Armored Protection | Corrugated Steel Tape Armor with Dual Water Blocking System |
| Tensile Strength | 1,800 N Self-Support Design |
| Cable Length | 2,000 / 3,000 / 4,000 Meters per Drum |
| Application | Backbone Network, FTTx, CCTV, CATV, Data Center and Enterprise Fiber Infrastructure |
| Fiber Standard | ITU-T G.652D OS2 Single-Mode |
|---|---|
| Fiber Diameter | 9/125μm |
| Fiber Type | Single-Mode Fiber (SMF) |
| Cable Structure | ARSS Multi-Tube Armored Double Jacket |
| Armor Type | Corrugated Polymer-Coated Steel Tape Armor |
| Jacket Type | Double HDPE Jacket |
| Strength Member | FRP Central Strength Member with Water Blocking E-Glass Yarn |
| Installation Type | Aerial, Direct Burial, Underground Duct and Indoor/Outdoor |
| Standards | ANSI/TIA-568.3-D, ISO/IEC 11801, ANSI/ICEA 640, Telcordia GR-20-CORE, ITU-T G.652D, IEC 60793, IEC 60794-1-2, EN 50173-1, TIS 2166, RoHS |
| Application | 10G, 40G, 100G Ethernet, Fiber Channel, FTTx, CATV, CCTV and Long-Distance Backbone Network |
| SMART FEATURES | |
|---|---|
| ARSS Self Support Design | Supports Aerial Installation Without Additional Messenger Wire |
| Multi-Tube Construction | Color-Coded Loose Tubes Protect Fiber Cores and Support High Fiber Density Applications |
| Double Jacket Protection | Dual HDPE Jacket Improves UV Resistance, Mechanical Strength and Environmental Durability |
| Steel Armored Protection | Corrugated Steel Tape Protects Against Rodents, Crushing and Mechanical Damage |
| Dual Water Blocking System | Water Blocking Tape and Water Blocking Yarn Prevent Moisture Penetration Throughout the Cable |
| GENERAL | |
|---|---|
| Fiber Count | 24 Core |
| Core / Cladding Size | 9/125μm Single-Mode Fiber |
| Cable Type | ARSS Multi-Tube Armored Double Jacket |
| Outer Jacket Color | Black |
| Cable Weight | Approximately 135kg/km |
| Maximum Tensile Strength | 1,800 N |
| Installation / Operating Temperature | -40°C to +70°C |
| Packing | 2,000 / 3,000 / 4,000m per Drum |
| Warranty | 30 Years |
Note: The LINK UFC9724MAD is a 24-core OS2 9/125μm single-mode ARSS multi-tube fiber optic cable with steel armored construction and a double HDPE jacket. It features an FRP central strength member, dual water-blocking protection, and a corrugated steel armor layer, providing superior tensile strength and durability for aerial, direct-buried, duct, and indoor/outdoor installations. It is ideal for backbone networks, FTTx, CCTV, CATV, and enterprise fiber infrastructure.
Important: The LINK UFC9724MAD is engineered for heavy-duty outdoor deployments with a maximum tensile strength of 1,800 N. Its ARSS multi-tube double-jacket construction provides enhanced resistance to UV exposure, moisture, rodent damage, impact, and harsh environmental conditions while supporting reliable long-distance 10G, 40G and 100G Ethernet backbone transmission.
จัดจำหน่าย By บริษัทโฟกัส ซิสเต็ม แอนด์ ดีไซน์ ช่างติดเเละซ้อมกล้องวงจรปิด พัทยา ชลบุรี
Datasheet
