| Features |
Description |
| Device Type |
Fiber Optic Patch Cord (LC/UPC to LC/UPC) |
| Fiber Type |
OM1 62.5/125μm Multi-Mode Fiber |
| Core Count |
2 Core (Duplex Structure) |
| Connector Types |
LC Connector (Side A) to LC Connector (Side B) |
| Polish Type |
UPC to UPC (Ultra Physical Contact) |
| Cable Construction |
2.0 mm Duplex Jacket |
| Jacket Material |
Orange FR-LSZH (Flame Retardant Low Smoke Zero Halogen) / OFNR |
| Installation |
Indoor Rack, Patch Panel, Equipment Cross-Connect |
| Water Protection |
Indoor Non-Waterproof Structure |
| Strength Member |
Aramid Yarn Reinforcement |
| Cable Length |
3.0 Meters |
| Application |
Telecommunication Networks, Data Centers, Legacy Networks, Gigabit Ethernet |
| Fiber Standard |
ITU-T G.651 OM1 Multi-Mode |
| Fiber Diameter |
62.5/125μm |
| Flame Rating |
FR-LSZH & OFNR (UL-1666) |
| Insertion Loss |
Typ. ≤ 0.15 dB (Max. ≤ 0.30 dB) |
| Return Loss |
UPC ≥ 30 dB |
| Standards |
ANSI/TIA/EIA-568-B.3/C.3, ISO/IEC 11801, ITU-T G.651, Telcordia GR-326-CORE, RoHS Compliant |
| Application |
Gigabit Ethernet, 100M/10M Networks, FTTx, CATV, and Enterprise Networks |
| SMART FEATURES |
| LC to LC Configuration |
Precision Factory-Terminated LC/UPC and LC/UPC Connectors for Reliable Duplex Interfacing |
| Low Insertion Loss |
High-Grade Zirconia Ceramic Ferrules Ensure Minimal Signal Attenuation and High Repeatability |
| Flame Retardant LSZH Jacket |
Orange FR-LSZH Sheath Minimizes Smoke and Halogen-Free Toxic Gas Emission During Fire |
| Factory Tested |
100% Factory Assembled and Tested for Insertion Loss and Return Loss Performance |
| High-Speed Network Support |
Supports Standard Legacy and Gigabit Ethernet Network Infrastructure |
| GENERAL |
| Fiber Count |
2 Core (Duplex) |
| Cable Diameter |
2.0 mm Duplex Profile |
| Maximum Tensile Load |
200N |
| Minimum Bending Radius |
30 mm |
| Operating / Storage Temperature |
-40°C to +85°C |
| Length |
3.0 Meters |
| Warranty |
30 Years |
Note: The LINK UFP422D21-03 is a 3-meter OM1 62.5/125μm multimode duplex fiber optic patch cord featuring LC/UPC to LC/UPC connectors and a 2.0mm orange FR-LSZH jacket. Factory-terminated and 100% tested for optimal performance, it delivers low insertion loss and high return loss. The cable complies with international TIA/EIA, ISO/IEC, and ITU-T standards, making it ideal for safe, legacy data center rack connections, distribution frames, and enterprise telecommunication networks.
Important: The LINK UFP422D21-03 is a 3-meter OM1 (62.5/125μm) multimode duplex patch cord equipped with LC/UPC and LC/UPC connectors, a 2.0mm orange FR-LSZH flame-retardant safety jacket, and high-precision zirconia ceramic ferrules. It supports legacy and Gigabit network applications and is ideal for professional indoor optical patching, equipment jumper links, and reliable fiber optic infrastructure routing.
