Specifications Uniview NSW3000-25GT1GP1GC-IN
| Features | Specifications |
|---|---|
Network |
|
| Switch Type | Gigabit Cloud Management Switch |
| Network Ports | 24 × 10/100/1000 Mbps RJ45 Ports |
| Additional RJ45 Port | 1 × 10/100/1000 Mbps RJ45 Port |
| SFP Port | 1 × Gigabit SFP Port |
| Combo Port | 1 × Gigabit Combo Port |
| Switching Capacity | 54 Gbps |
| Forwarding Performance | 40.176 Mpps |
| Packet Buffer | 4 Mbit |
| MAC Address Table | 8K |
PoE |
|
| PoE Standard | IEEE 802.3af / IEEE 802.3at |
| Priority Ports | Ports 1–8 |
Management |
|
| Management | Cloud Management via Software, Web Interface and App |
| Cloud Access | Supported via QR Code Scanning |
| VLAN | Access and Trunk Modes, up to 32 VLANs, VLAN ID 1–4094 |
| Link Aggregation | Supported, 2 Uplink Ports |
| Port Mirroring | N:1 Port Mirroring |
| Port Isolation | Supported for Downlink Ports |
| Loop Detection | Supported |
| QoS | Port Rate Limitation and Broadcast Storm Control |
| Network Topology | Automatically Discovers Connected Video Devices and Generates Network Topology |
| Device Management | Configuration, Firmware Upgrade, Restart, Factory Reset, Import/Export Configuration and Log Export |
Working Mode |
|
| Extend Mode | Communication Distance up to 250 m with 10 Mbps Auto-Negotiation Rate |
| Port Priority | Priority Packets are Forwarded First When the Switch is Fully Loaded |
| Port Abnormal Alarm | Supported via Management Software |
Standards |
|
| Network Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at and IEEE 802.3az |
Power & Environment |
|
| Power Supply | AC 100–240 V, 50/60 Hz |
| Maximum Power Consumption | 18 W |
| Cooling | 1 × Cooling Fan |
| Operating Temperature | 0°C to 45°C |
| Operating Humidity | 5%–90% RH, Non-Condensing |
Physical |
|
| Housing | Metal |
| Dimensions | 440 × 189.8 × 44 mm |
| Weight | 1.85 kg |
Note: The Uniview NSW3000-25GT1GP1GC-IN is a Gigabit Cloud Management Switch designed for centralized network management. It provides 24 × Gigabit RJ45 ports, an additional Gigabit RJ45 port, one Gigabit SFP port and one Gigabit Combo port. The switch supports VLAN, link aggregation, port mirroring, port isolation, loop detection and QoS functions. It also supports Extend Mode for communication distances of up to 250 m at a 10 Mbps auto-negotiation rate, making it suitable for surveillance and network infrastructure applications.
