| Features |
Description |
| Product Type |
Passive Optical Splitter |
| Series |
e-Lighten Passive Optical Splitter |
| Optical Configuration |
2-In 32-Out Uniform Optical Splitter |
| Optical Split Ratio |
1:32 |
| Uplink Optical Ports |
2 × SC |
| Splitter Downlink Ports |
32 × SC |
| Operating Wavelength |
1260–1650nm |
| Power Requirement |
None / Passive |
| OPTICAL SPECIFICATIONS |
| Splitter Type |
Uniform Optical Splitter |
| Optical Input Ports |
2 |
| Optical Output Ports |
32 |
| Split Ratio |
1:32 |
| Optical Connector |
SC |
| Operating Wavelength |
1260–1650nm |
| Insertion Loss |
≤17.7dB |
| Port Insertion Loss Uniformity |
≤1.5dB |
| Return Loss |
≥50dB |
| Polarization-Dependent Loss |
≤0.3dB |
| Temperature-Dependent Loss |
≤0.3dB |
| Wavelength-Dependent Loss |
0.4dB at 1310nm ±40nm / 1550nm ±40nm |
| Maximum Input Power |
500mW |
| NETWORK APPLICATION |
| Network Type |
Passive All-Fiber LAN |
| Application |
Reyee e-Lighten Optical Access Network |
| Topology |
Point-to-Multipoint Optical Distribution |
| Fiber Connection |
Direct Fiber Connection |
| Passive Aggregation |
Supported |
| Plug and Play |
Supported |
| Power Requirement |
No Power Required |
| INSTALLATION |
| Rack Mounting |
Supported |
| Wall Mounting |
Supported |
| Waterproof Enclosure |
Compatible |
| Standalone Installation |
Supported |
| Combined Installation |
Supported |
| Mounting Type |
Rack / Wall Mounting |
| MECHANICAL |
| Enclosure Material |
Durable Iron Casing |
| Dimensions |
220 × 130 × 42mm |
| Net Weight |
0.98kg |
| Design |
Compact Metal Enclosure |
| ENVIRONMENT & RELIABILITY |
| Operating Temperature |
-40°C to +85°C |
| Power Consumption |
0W – Passive Device |
| Maximum Input Power |
500mW |
| Reliability |
High Reliability |
| Enclosure |
Iron Casing |
| GENERAL |
| Product Type |
2-In 32-Out Passive Optical Splitter |
| Fiber Interface |
SC |
| Number of Inputs |
2 |
| Number of Outputs |
32 |
| Split Ratio |
1:32 |
| Power Supply |
Not Required |
| Dimensions |
220 × 130 × 42mm |
| Net Weight |
0.98kg |
Note: The Reyee RG-SPL2032-SC is a 2-In 32-Out Uniform Passive Optical Splitter designed for Reyee e-Lighten optical access networks. It features 2 optical input ports and 32 optical output ports with a 1:32 split ratio. The splitter supports an operating wavelength of 1260–1650nm, direct fiber connection and passive aggregation without requiring electrical power. It features a durable iron casing and supports rack-mounted or wall-mounted installation.
Important: The Reyee RG-SPL2032-SC is a Passive Optical Splitter featuring 2 × SC optical input ports and 32 × SC optical output ports with a 1:32 split ratio. It requires no power supply and supports 1260–1650nm operating wavelength, passive aggregation and direct fiber connection. The unit measures 220 × 130 × 42mm, weighs approximately 0.98kg and operates from -40°C to +85°C.
