ST4000VX015-520

ST4000VX015-520

Seagate SkyHawk ST4000VX015-520

4TB Surveillance Hard Drive

  • 4TB capacity with 3.5-inch form factor
  • SATA 6Gb/s interface with 5400RPM
  • 256MB cache with up to 180MB/s transfer rate
  • CMR recording for reliable surveillance workloads
  • Supports up to 64 HD cameras and 24/7 operation
  • 1 million-hour MTBF with 3-year warranty
หมวดหมู่: , ป้ายกำกับ:

Specifications Seagate ST4000VX015-520

Features Specifications
Product Type SkyHawk Surveillance Hard Drive
Capacity 4TB
Form Factor 3.5-inch
Interface SATA 6Gb/s
Recording Technology CMR
Rotation Speed 5400 RPM
Cache 256MB
Maximum Sustained Transfer Rate Up to 180 MB/s

Surveillance Features

Features Specifications
Surveillance Workload Designed for 24/7 Video Surveillance
Cameras Supported Up to 64 Cameras
Drive Bays Supported Up to 16 Bays
SkyHawk Health Management Supported
Rotational Vibration Sensor Supported
Load/Unload Cycles Up to 600,000
Annual Workload Rate Up to 180TB/year
MTBF Up to 1,000,000 Hours

Power & Reliability

Features Specifications
Average Operating Power Approx. 3.7 W
Idle Power Approx. 2.5 W
Startup Current 1.8 A at 12V
Operating Temperature 0°C to 65°C
Non-Operating Temperature -40°C to 70°C
Nonrecoverable Read Error Rate 1 per 1014 bits read

General

Features Specifications
Height 20.20 mm
Width 101.6 mm
Depth 146.99 mm
Weight Approx. 630 g
Warranty 3 Years Limited Warranty

Note: ST4000VX015-520 is a 4TB Seagate SkyHawk surveillance HDD designed for continuous 24/7 video recording in CCTV and NVR systems.

Important: Actual recording capacity and supported camera count may vary depending on camera resolution, bitrate, recording mode and NVR configuration.
