Specifications TP-Link Archer AX23
| Features | Specifications |
|---|---|
| Product Type | AX1800 Dual-Band Wi-Fi 6 Router |
| Wireless Standard | IEEE 802.11ax/ac/n/a 5 GHz; IEEE 802.11ax/n/b/g 2.4 GHz |
| Wi-Fi Speed | 5 GHz: 1201 Mbps; 2.4 GHz: 574 Mbps |
| Wi-Fi Class | AX1800 |
| Antennas | 4 × Fixed High-Performance Antennas |
| Beamforming | Supported |
| Wi-Fi Capacity | Dual-Band, OFDMA, Airtime Fairness, 4 Streams |
| Working Modes | Router Mode, Access Point Mode |
Wireless Features
| Features | Specifications |
|---|---|
| 2.4 GHz | 574 Mbps, 802.11ax |
| 5 GHz | 1201 Mbps, 802.11ax |
| OFDMA | Supported |
| Airtime Fairness | Supported |
| 4 Streams | Supported |
| Guest Network | 1 × 5 GHz Guest Network; 1 × 2.4 GHz Guest Network |
| Wi-Fi Encryption | WPA, WPA2, WPA3, WPA/WPA2-Enterprise (802.1x) |
| Wi-Fi Mesh | OneMesh and EasyMesh supported |
Network & Hardware
| Features | Specifications |
|---|---|
| WAN Port | 1 × Gigabit WAN Port |
| LAN Ports | 4 × Gigabit LAN Ports |
| Processor | Dual-Core CPU |
| Buttons | WPS/Wi-Fi, Reset, Power On/Off |
| Power Supply | 12 V ⎓ 1.5 A |
| Dimensions | 260.2 × 135 × 38.6 mm |
Security & Management
| Features | Specifications |
|---|---|
| Network Security | SPI Firewall, Access Control, IP & MAC Binding, Application Layer Gateway |
| VPN Server | OpenVPN, PPTP, L2TP, WireGuard |
| WAN Types | Dynamic IP, Static IP, PPPoE, PPTP, L2TP |
| Parental Controls | URL Filtering, Time Controls |
| Quality of Service | QoS by Device |
| NAT Forwarding | Port Forwarding, Port Triggering, DMZ, UPnP, Virtual Server |
| IP Protocol | IPv4, IPv6 |
| Management | TP-Link Tether App, Web Management, TP-Link ID, DDNS |
Environment
| Features | Specifications |
|---|---|
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -40°C to 70°C |
| Operating Humidity | 10%–90% RH, non-condensing |
| Storage Humidity | 5%–90% RH, non-condensing |
| Certifications | FCC, CE, RoHS |
Note: Hardware specifications and supported features may vary depending on the hardware version and regional version of Archer AX23.
