TP-Link Omada EAP610

TP-Link Omada EAP610

TP-Link Omada EAP610

AX1800 Dual-Band Wi-Fi 6 Ceiling Mount Access Point

  • Wi-Fi 6 with speeds up to 574Mbps (2.4GHz) and 1201Mbps (5GHz)
  • 1× Gigabit Ethernet port with 802.3at PoE+ support
  • 2× 4dBi antennas (2.4GHz) and 2× 5dBi antennas (5GHz)
  • Supports 250+ concurrent clients with OFDMA and MU-MIMO
  • Supports Omada Mesh, seamless roaming and centralized management
  • Ceiling/wall-mount design with dimensions of 160 × 160 × 33.6mm
หมวดหมู่: , , ป้ายกำกับ:

Specifications TP-Link Omada EAP610

Features Specifications

Wireless
Wi-Fi Standard IEEE 802.11ax/ac/n/g/b/a (Wi-Fi 6)
Wireless Speed Up to 1,775 Mbps (574 Mbps on 2.4 GHz + 1,201 Mbps on 5 GHz)
Frequency 2.4 GHz and 5 GHz
Wireless Technology OFDMA, MU-MIMO, 1024-QAM, Beamforming, Band Steering and Airtime Fairness
SSID Up to 16 SSIDs (8 per band)
Concurrent Clients 250+ clients

Hardware
Ethernet Port 1× Gigabit Ethernet (RJ-45)
Antenna Internal Omni Antenna, 2× 4 dBi on 2.4 GHz and 2× 5 dBi on 5 GHz
Button Reset
Power Supply 802.3at PoE, 48 V Passive PoE, or 12 V DC power adapter
Power Consumption Up to 11.0 W via PoE / 9.9 W via DC

Omada Features
Management Omada App, Omada Cloud-Based Controller, Omada Hardware Controller and Omada Software Controller
Mesh Omada Mesh for flexible wireless deployment
Roaming Seamless Roaming for uninterrupted connectivity between access points
Network Optimization Automatic Channel Assignment, Transmit Power Control, Load Balance, Rate Limit and Wireless Scheduling
Guest Network Captive Portal Authentication

Security
Wireless Security WPA-Personal/Enterprise, WPA2-Personal/Enterprise and WPA3-Personal/Enterprise
Network Security Access Control, MAC Address Filtering, Client Isolation, SSID-to-VLAN Mapping, Rogue AP Detection and 802.1X

Management
Management Interface Web-based Management, Omada App, SSH and SNMP v1/v2c/v3
Cloud Access Supported through Omada Controller
Management VLAN Supported
Zero-Touch Provisioning Supported with Omada Cloud-Based Controller

Physical & Environment
Dimensions 160 × 160 × 33.6 mm
Mounting Ceiling / Wall Mounting and Junction Box Mounting
Operating Temperature 0°C to 40°C
Storage Temperature -40°C to 70°C
Operating Humidity 10%–90% RH, non-condensing
Storage Humidity 5%–90% RH, non-condensing
Certifications CE, FCC, RoHS

Note: Specifications may vary depending on the hardware version of the TP-Link EAP610.
