Specifications TP-Link Omada EAP653
| Features | Specifications |
|---|---|
| Product Type | AX3000 Ceiling Mount Dual-Band Wi-Fi 6 Access Point |
| Wireless Standard | IEEE 802.11ax/ac/n/g/b/a |
| Wireless Frequency | 2.4 GHz and 5 GHz |
| Wireless Speed | 2.4 GHz: Up to 574 Mbps 5 GHz: Up to 2402 Mbps |
| Ethernet Interface | 1× Gigabit Ethernet Port (RJ-45) |
| Power Supply | 802.3at PoE+ / 48V Passive PoE / 12V DC |
| Maximum Power Consumption | Version-dependent; approximately 13–15 W |
| Antenna Type | Internal Omni-directional Antennas |
| Wireless Technology | OFDMA, MU-MIMO, Beamforming, 1024-QAM and HE160 (160 MHz) |
| SSID Support | Up to 16 SSIDs (8 SSIDs per band) |
| Wireless Security | WPA-Personal/Enterprise, WPA2-Personal/Enterprise and WPA3-Personal/Enterprise |
| Network Features | VLAN, Band Steering, Load Balance, Airtime Fairness, Rate Limit and Client Isolation |
| Omada Features | Omada Mesh, Seamless Roaming, Captive Portal and Centralized Management |
| Management | Omada Hardware Controller, Software Controller and Cloud-Based Controller |
| Management Protocols | SNMP v1/v2c/v3, SSH, HTTP/HTTPS and Syslog |
| Concurrent Clients | 250+ |
| Coverage | Up to 140 m² (1500 ft²), depending on the environment |
| Bluetooth | Bluetooth 5.2 |
| Mounting | Ceiling Mount, Wall Mount and Junction Box Mount |
| Dimensions | 160 × 160 × 33.6 mm |
| Operating Temperature | 0°C to 40°C |
| Operating Humidity | 10–90% RH, Non-condensing |
| Certifications | CE, FCC and RoHS |
Important: Specifications such as antenna gain and power consumption may vary depending on the hardware version. Please verify the device version before installation.
