Specifications TP-Link Omada EAP230-Wall
| Features | Specifications |
|---|---|
Product Overview |
|
| Product Type | AC1200 Wireless MU-MIMO Gigabit Wall-Plate Access Point |
| Wi-Fi Standard | Wi-Fi 5 (IEEE 802.11ac) |
| Wireless Speed | 5 GHz: Up to 867 Mbps; 2.4 GHz: Up to 300 Mbps |
| Total Wireless Speed | Up to 1167 Mbps |
| Installation | Wall-Plate Mounting |
Wireless |
|
| Frequency | 2.4 GHz and 5 GHz |
| Wireless Standards | IEEE 802.11n/g/b/ac |
| MU-MIMO | 2×2 MU-MIMO |
| Antennas | 2 × Dual-Band Antennas |
| Antenna Gain | 2.4 GHz: 2 × 4 dBi; 5 GHz: 2 × 3.6 dBi |
| SSIDs | Up to 16 SSIDs, 8 per band |
| Concurrent Clients | 200+ |
| Coverage | Up to 25 m² (300 ft²), depending on environmental conditions |
| Transmission Power | CE: ≤20 dBm at 2.4 GHz; ≤18 dBm at 5 GHz |
Network Interfaces |
|
| Uplink Port | 1 × 10/100/1000 Mbps Gigabit Ethernet Port |
| Downlink Port | 1 × 10/100/1000 Mbps Gigabit Ethernet Port |
| PoE | 802.3af/802.3at PoE |
Wireless Features |
|
| Wireless Functions | Automatic Channel Assignment, Transmit Power Control, QoS (WMM), Seamless Roaming, Load Balance, Rate Limit, Band Steering, Beamforming and Wireless Scheduling |
| Seamless Roaming | 802.11k/v |
| Wireless Security | WEP, WPA, WPA2-PSK and WPA2-Enterprise |
| Guest Network | Captive Portal Authentication and Guest Network Support |
| Access Control | Wireless MAC Address Filtering, Client Isolation and SSID-to-VLAN Mapping |
| Rogue AP Detection | Supported |
| 802.1X | Supported |
Omada Management |
|
| Centralized Management | Omada Cloud-Based Controller, Omada Hardware Controller and Omada Software Controller |
| Omada App | Supported |
| Cloud Access | Supported with compatible Omada Controller |
| Zero-Touch Provisioning | Supported with Omada Cloud-Based Controller |
| Management | Web-Based Management, SSH and L3 Management |
| Management VLAN | Supported |
| Multi-Site Management | Supported |
| SNMP | SNMP v1/v2c/v3 |
Hardware |
|
| Power Supply | 802.3af/802.3at PoE |
| Maximum Power Consumption | 7 W |
| Buttons | LED/Wi-Fi Button, RESET |
| Hardware Watchdog | Supported |
| Dimensions | 86.8 × 86.8 × 30.2 mm |
| Mounting | Wall-Plate Mounting |
Operating Environment |
|
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -40°C to 70°C |
| Operating Humidity | 10% to 90% RH, non-condensing |
| Storage Humidity | 5% to 90% RH, non-condensing |
Package Contents |
|
| Package Includes | Omada EAP230-Wall, Mounting Screw and Installation Guide |
Note: TP-Link Omada EAP230-Wall is an AC1200 dual-band Wi-Fi 5 wall-plate access point with 867 Mbps on 5 GHz, 300 Mbps on 2.4 GHz, 2 Gigabit Ethernet ports and 802.3af/802.3at PoE support.
Important: The EAP230-Wall is designed for indoor wall installation and is intended to provide dedicated Wi-Fi connectivity for individual rooms such as hotels, offices and dormitories. Actual wireless coverage and throughput depend on the installation environment and connected devices.
