| Features |
Specifications |
| Product Type |
10-Port Gigabit Desktop Switch with 8-Port PoE+ |
| Interfaces |
9 × 10/100/1000 Mbps RJ45 Ports |
| Uplink Port |
1 × 1000 Mbps Combo SFP/RJ45 Port |
| PoE Standard |
IEEE 802.3af/at |
| PoE Ports |
8 Ports, up to 30W per port |
| PoE Power Budget |
123W |
| Switching Capacity |
20 Gbps |
| Packet Forwarding Rate |
14.88 Mpps |
| MAC Address Table |
4K |
| Jumbo Frame |
16 KB |
Layer 2 & Layer 3 Features
| Features |
Specifications |
| VLAN |
Not Supported |
| Link Aggregation |
Not Supported |
| Spanning Tree |
Not Supported |
| IGMP Snooping |
Not Supported |
| DHCP |
Not Supported |
| Static Routing |
Not Supported |
| Transmission Method |
Store-and-Forward |
| Flow Control |
IEEE 802.3x Flow Control, Backpressure |
Security & QoS
| Features |
Specifications |
| Isolation Mode |
Ports 1–4 / 5–8 |
| Priority Mode |
Ports 1–2 |
| PoE Auto Recovery |
Ports 1–8 |
| PoE Power Management |
Intelligent Power Management |
| MAC Address Management |
Auto-Learning and Auto-Aging |
| Bandwidth Control |
Not Supported |
| Traffic Management |
Isolation Mode, Priority Mode, Extend Mode |
PoE & Advanced Functions
| Features |
Specifications |
| Extend Mode |
Up to 250 m PoE Data and Power Transmission |
| Extend Mode Ports |
Ports 1–4 |
| Extend Mode Speed |
Up to 10 Mbps |
| Priority Mode |
Ports 1–2 |
| Isolation Mode |
Ports 1–4 / 5–8 |
| PoE Auto Recovery |
Automatically Detects and Reboots Unresponsive PoE Devices |
| Plug and Play |
Supported |
Hardware & General
| Features |
Specifications |
| Fan |
Fanless |
| Power Supply |
External Power Adapter, 53.5VDC / 2.43A |
| Max Power Consumption |
7.93W without PD; 141.40W with 123W PD |
| Mounting |
Desktop / Wall Mountable |
| Physical Security Lock |
Supported |
| Dimensions |
209 × 126 × 26 mm |
| Operating Temperature |
0°C to 40°C |
| Storage Temperature |
-40°C to 70°C |
| Operating Humidity |
10%–90% RH, non-condensing |
| Certifications |
FCC, CE, RoHS |
Note: TL-SG1210MP provides 123W total PoE power with up to 30W per PoE+ port and supports up to 250 m data and power transmission in Extend Mode.
Important: Extend Mode reduces port speed to 10 Mbps. Actual transmission distance may vary depending on the PoE device power consumption and cable quality.
