| Features |
Description |
| Product Type |
5MP Outdoor Full-Color Bullet Network Camera |
| Resolution |
5MP (2880 × 1620) |
| Image Sensor |
1/2.7″ Progressive Scan CMOS |
| Lens |
Fixed Focal Lens, 2.8 mm / 4 mm / 6 mm |
| Aperture |
F1.6 |
| Full-Color Night Vision |
24-Hour Full-Color |
| IR / White Light Range |
Up to 30 m |
| AI Detection |
People & Vehicle Analytics, Human & Vehicle Classification |
| Smart Detection |
Intrusion, Line-Crossing, Region Entering/Exiting, Loitering and Object Abandoned/Removal |
| Active Defense |
White Light Flashing and Audible Warning |
| Audio |
Two-Way Audio with Built-in Microphone and Speaker |
| Connectivity |
10/100 Mbps Ethernet with PoE |
| Storage |
MicroSD Card up to 512GB |
| Weather Protection |
IP67 |
| CAMERA |
| Image Sensor |
1/2.7″ Progressive Scan CMOS |
| Maximum Resolution |
2880 × 1620 |
| Shutter Speed |
1/3 to 1/10000 s |
| Minimum Illumination |
0.005 Lux; 0 Lux with IR/White Light |
| Slow Shutter |
Yes |
| Day/Night Mechanism |
IR Cut Filter |
| Day/Night Switch |
Unified / Scheduled / Auto |
| LENS |
| Lens Type |
Fixed Focal Lens |
| Focal Length |
2.8 mm / 4 mm / 6 mm |
| Aperture |
F1.6 |
| Lens Mount |
M12 × P0.5 |
| FOV – 2.8 mm |
Horizontal 109° / Vertical 57° / Diagonal 128° |
| FOV – 4 mm |
Horizontal 90° / Vertical 48° / Diagonal 107° |
| FOV – 6 mm |
Horizontal 56° / Vertical 30.5° / Diagonal 66° |
| DORI DISTANCE |
| 2.8 mm |
Detect 63 m / Observe 26 m / Recognize 12 m / Identify 6 m |
| 4 mm |
Detect 80 m / Observe 33 m / Recognize 16 m / Identify 8 m |
| 6 mm |
Detect 120 m / Observe 50 m / Recognize 24 m / Identify 12 m |
| ANGLE ADJUSTMENT |
| Pan |
0° to 360° |
| Tilt |
0° to 90° |
| Rotation |
0° to 360° |
| Adjustment Type |
Manual |
| ILLUMINATOR |
| IR LED |
2 × IR LEDs, 850 nm, up to 30 m |
| White LED |
2 × White LEDs, up to 30 m |
| Illuminator Control |
Auto / Scheduled / Always On / Always Off |
| IMAGE & VIDEO |
| Maximum Resolution |
2880 × 1620 |
| Frame Rate |
Up to 30 fps at 60Hz |
| Main Stream Resolution |
2880 × 1620 / 2688 × 1520 / 2304 × 1296 / 2048 × 1280 / 1920 × 1080 / 1280 × 720 |
| Sub-Stream Resolution |
704 × 576 / 640 × 480 / 352 × 288 / 320 × 240 |
| Video Compression |
H.265+ / H.265 / H.264+ / H.264 |
| Bit Rate Control |
CBR / VBR |
| Main Stream Bit Rate |
256 Kbps to 6 Mbps |
| Sub-Stream Bit Rate |
64 Kbps to 512 Kbps |
| Image Enhancement |
BLC / 3D DNR / HLC / SmartIR |
| WDR |
120 dB |
| SNR |
≥ 52 dB |
| Privacy Mask |
Up to 4 Masks |
| ROI |
1 Region |
| AUDIO |
| Audio Communication |
Two-Way Audio |
| Microphone |
Built-in Microphone, recording within approximately 5 m radius |
| Speaker |
Built-in Speaker |
| Audio Sampling Rate |
8 kHz |
| Audio Bit Rate |
64 Kbps (G.711 A-law) |
| Noise Filtering |
Supported |
| AI & SMART DETECTION |
| People & Vehicle Analytics |
Supported |
| Human & Vehicle Classification |
Supported |
| People Detection |
Supported |
| Vehicle Detection |
Supported |
| Area Intrusion Detection |
Supported |
| Line-Crossing Detection |
Supported |
| Region Entering Detection |
Supported |
| Region Exiting Detection |
Supported |
| Loitering Detection |
Supported |
| Object Abandoned Detection |
Supported |
| Object Removal Detection |
Supported |
| Motion Detection |
Supported |
| Video Tampering Detection |
Supported |
| Scene Change Detection |
Supported |
| ACTIVE DEFENSE |
| Audible Warning |
Supported |
| White Light Flashing |
Supported |
| Alarm Linkage |
Memory Card Recording / Message Push / Audible Warning / White Light Flashing |
| NETWORK |
| Network Interface |
1 × RJ45 10/100 Mbps Self-Adaptive Ethernet Port, PoE |
| PoE |
IEEE 802.3af/at, Class 0 |
| ONVIF |
Profile S |
| Network Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SNMP, IEEE 802.1X |
| Cloud |
Supported |
| Simultaneous Live View |
3 Main Streams + 3 Sub-Streams |
| Management |
VIGI App / VIGI Security Manager / Web UI / NVR UI |
| STORAGE |
| MicroSD |
Built-in MicroSD Card Slot, up to 512GB |
| Local Recording |
Supported |
| INTERFACE |
| Ethernet |
1 × 10/100 Mbps RJ45 with PoE |
| Power |
12V DC Power Port |
| Reset |
1 × Reset Button |
| Built-in Microphone |
Supported |
| Built-in Speaker |
Supported |
| Alarm Interface |
N/A |
| GENERAL |
| Material |
Plastic |
| Protection |
IP67 |
| Operating Temperature |
-30°C to 60°C |
| Storage Temperature |
-40°C to 60°C |
| Operating Humidity |
95% RH or Less, Non-Condensing |
| Power Supply |
12V DC ±5%, Max. 9W / PoE 802.3af/at, Class 0, Max. 10.5W |
| Dimensions |
78.42 × 186.88 × 71.55 mm |
| Certifications |
CE, NTRA, VCCI, KC, BSMI, FCC, IC |
Note: The TP-Link VIGI C350 is a 5MP outdoor full-color bullet network camera featuring a 1/2.7″ Progressive Scan CMOS sensor, F1.6 aperture, 24-hour full-color imaging, up to 30 m IR and white-light illumination, People & Vehicle Analytics, Human & Vehicle Classification, Smart Detection, Active Defense, Two-Way Audio, MicroSD storage up to 512GB, PoE and IP67 protection.
Important: The VIGI C350 has a maximum resolution of 2880 × 1620 (5MP). It supports 2.8 mm / 4 mm / 6 mm lens variants, although the Thailand specification page currently lists the focal length field as 4 mm. For product listing purposes, check the physical lens variant/SKU before specifying the exact FOV.
