| Features |
Description |
| Device Type |
Layer 3 Managed PoE Switch |
| Ethernet Ports |
16 × Gigabit RJ45 |
| PoE Ports |
12 × 802.3af/at PoE+, 4 × 802.3bt PoE++ |
| PoE Budget |
180 W Total |
| Uplink Ports |
2 × 10G SFP+ |
| Switching Capacity |
72 Gbps |
| Forwarding Rate |
53.57 Mpps |
| Management |
UniFi Network Controller |
| Cooling |
Smart Fan Cooling |
| Power Supply |
100–240V AC, Internal PSU |
| Device Type |
Layer 3 Managed Switch |
| Ethernet Ports |
16 × 10/100/1000 Mbps RJ45 |
| PoE Ports |
12 × PoE+ (802.3af/at), 4 × PoE++ (802.3bt) |
| PoE Budget |
180 W |
| Uplink |
2 × 10G SFP+ |
| Management |
UniFi Network Controller |
| PERFORMANCE |
| Switching Capacity |
72 Gbps |
| Forwarding Rate |
53.57 Mpps |
| Layer Support |
Layer 2 / Layer 3 |
| MAC Address Table |
32K Entries |
| Jumbo Frame |
9 KB |
| NETWORK |
| Management |
UniFi Network Application |
| Features |
VLAN, ACL, QoS, STP/RSTP/MSTP, LACP, DHCP Snooping, IGMP Snooping |
| Routing |
Static Routing, Inter-VLAN Routing |
| LED Indicators |
Status, Link/Activity, PoE |
| GENERAL |
| Power Input |
100–240V AC, 50/60Hz |
| Cooling |
Smart Fan |
| Operating Temperature |
-5°C to 40°C |
| Dimensions |
325.1 × 160 × 43.7 mm |
| Rack Mount |
1U Rackmount (Kit Included) |
| Certifications |
CE, FCC, IC |
Note: Product specifications and software features are subject to change without prior notice. Please refer to the latest official documentation before deployment.
Important: The 180W PoE budget is shared across all PoE ports. Ensure the combined power requirements of connected devices do not exceed the available PoE power budget.
