Specifications Uniview MW3222-V2
| Display |
| Product Type |
22-inch LED CCTV Monitor |
| Backlight |
ELED |
| Panel Size |
22 inches |
| Panel Type |
VA |
| Pixel Pitch |
0.24 × 0.24 mm |
| Resolution |
1920 × 1080 pixels, Full HD |
| Color Support |
16.7 million colors |
| Brightness |
250 cd/m² |
| Contrast Ratio |
3000:1 |
| Refresh Rate |
100 Hz |
| Response Time |
20 ms |
| Viewing Angle |
178° horizontal / 178° vertical |
| Display Size |
478.6 × 260.2 mm |
| Color Gamut |
72% NTSC |
| Surface Treatment |
Haze 25%, 3H anti-glare surface |
| Operation Hours |
24/7 continuous operation |
| Interface |
| Video Input |
1 × VGA, supports up to 1920 × 1080 @ 60 Hz
1 × HDMI, supports up to 1920 × 1080 @ 100 Hz |
| Audio Input |
1 × 3.5 mm MiniJack |
| Audio |
| Built-in Speaker |
2 × 1.5 W speakers |
| Mounting |
| VESA Mounting |
100 × 100 mm |
| Wall-Mounted Thread |
4 × M4 screw holes, 10 mm deep |
| OSD |
| Multi-Language |
English, German, French, Spanish, Italian, Dutch, Chinese, Japanese, Korean, Russian, Portuguese, and Turkish |
| General |
| Power Supply |
DC 12 V, 2 A |
| Typical Power Consumption |
<24 W |
| Standby Power Consumption |
<0.5 W |
| Dimensions Without Pedestal |
493.1 × 290.8 × 50.5 mm (W × H × D) |
| Dimensions With Pedestal |
493.1 × 378.6 × 200.0 mm (W × H × D) |
| Package Dimensions |
557 × 370 × 140 mm (W × H × D) |
| Weight |
Net: 2.3 kg, Gross: 3.4 kg |
| Operating Temperature |
0°C to 40°C |
| Operating Humidity |
10%–90% RH, non-condensing |
| Storage Temperature |
10°C to 60°C |
| Storage Humidity |
10%–90% RH, non-condensing |
| Material |
Plastic |
| Lifetime |
30,000 hours |
| MTBF |
50,000 hours |
| Certifications |
CE, FCC |
Note: The Uniview MW3222-V2 is a 22-inch Full HD LED CCTV monitor featuring a VA panel, 1920 × 1080 resolution, 250 cd/m² brightness, 3000:1 contrast ratio, and a 100 Hz refresh rate. It provides a 178° viewing angle and is designed for continuous 24/7 operation.
Important: The MW3222-V2 provides 1 × HDMI and 1 × VGA video inputs, 1 × 3.5 mm audio input, and built-in 2 × 1.5 W speakers. It supports 100 × 100 mm VESA mounting and uses a DC 12 V, 2 A power supply, making it suitable for NVR/DVR surveillance monitoring applications.
