WI-Tek WI-PCES306G(V2)

Cloud Easy Smart 6-Port Gigabit PoE+ Switch

  • 4 × Gigabit PoE+ ports and 2 × Gigabit uplink ports
  • 65W total PoE budget with 802.3af/at support
  • Supports Wi-Tek Cloud management and remote monitoring
  • Supports Auto Loop Prevention and ONVIF IP camera detection
  • Supports Link Aggregation and QoS for network optimization
  • Real-time alarm notifications for easier network maintenance
หมวดหมู่: , , ป้ายกำกับ:

Specifications Wi-Tek WI-PCES306G(V2)

Features Description
Product Type Cloud Easy Smart Gigabit PoE Switch
PoE Ports 4 × 10/100/1000Mbps RJ45 PoE+
Uplink Ports 2 × 10/100/1000Mbps RJ45
PoE Standard IEEE 802.3af/at
PoE Budget Up to 60W
Switching Capacity 12Gbps
Forwarding Rate 8.93Mpps
Management Web Management / Wi-Tek Cloud / Mobile App
HARDWARE
PoE Ports 4 × 10/100/1000Mbps RJ45
Uplink Ports 2 × 10/100/1000Mbps RJ45
PoE Port 1–4 IEEE 802.3af/at, up to 30W per port
MAC Address Table 8K Entries
Packet Buffer 4Mbit
Jumbo Frame Up to 9216 Bytes
PERFORMANCE
Switching Capacity 12Gbps
Forwarding Rate 8.93Mpps
Forwarding Mode Store and Forward
MAC Address Table 8K Entries
POE
PoE Standard IEEE 802.3af / 802.3at
PoE Ports 4 × Gigabit PoE+
PoE Power per Port Up to 30W
Total PoE Budget Up to 60W
PoE Watchdog Supported
SMART FEATURES
Loop Prevention Automatic Anti-Loop
ONVIF Automatically Detects Compatible IP Cameras
Link Aggregation Supported
QoS Supported
VLAN Port VLAN / Port Isolation
Port Mirroring Supported
Storm Control Supported
Bandwidth Control Supported
Cable Diagnostics Supported
MANAGEMENT
Web Management Supported
Cloud Management Wi-Tek Cloud
Mobile App Remote Monitoring and Configuration
Alarm Notification Supported
Firmware Upgrade Supported
POWER & GENERAL
Power Supply 100–240V AC, 50/60Hz
PoE Budget Up to 60W
Dimensions 168 × 94 × 32mm
Installation Desktop / Wall Mount
Design Fanless

Note: The Wi-Tek WI-PCES306G(V2) is a 6-port Cloud Easy Smart Gigabit PoE Switch featuring 4 × Gigabit PoE+ ports and 2 × Gigabit uplink ports. It supports up to 60W total PoE power, Wi-Tek Cloud management, ONVIF IP camera detection, automatic loop prevention, link aggregation and QoS.

Important: The WI-PCES306G(V2) is a Gigabit PoE+ switch with 4 × 10/100/1000Mbps PoE ports and 2 × 10/100/1000Mbps uplink ports. Each PoE port supports up to 30W, with a total PoE budget of 60W. It also supports Wi-Tek Cloud management, ONVIF, link aggregation and automatic loop prevention.
