| Features |
Description |
| Product Type |
Cloud L2+ Managed Gigabit PoE Switch |
| PoE Ports |
8 × 10/100/1000Mbps RJ45 PoE+ |
| Uplink Ports |
2 × 1000Mbps SFP Slots |
| Console Port |
1 × Console Port |
| PoE Standard |
IEEE 802.3af/at |
| PoE Budget |
Up to 140W |
| Switching Capacity |
20Gbps |
| Forwarding Rate |
14.88Mpps |
| Layer |
Layer 2+ |
| Management |
Web / CLI / SNMP / RMON / Wi-Tek Cloud |
| HARDWARE |
| Downlink Ports |
8 × 10/100/1000Mbps RJ45 |
| Uplink Ports |
2 × 1000Mbps SFP Slots |
| Management Port |
1 × Console Port |
| PoE Ports |
Port 1–8 |
| MAC Address Table |
8K Entries |
| Packet Buffer |
4.1Mbit |
| Jumbo Frame |
Up to 10KB |
| Memory |
128MB DDR3 |
| Flash |
32MB |
| PERFORMANCE |
| Switching Capacity |
20Gbps |
| Forwarding Rate |
14.88Mpps |
| Forwarding Mode |
Store and Forward |
| MAC Address Table |
8K Entries |
| Packet Buffer Memory |
4.1Mbit |
| Jumbo Frame |
Up to 10KB |
| Standards |
IEEE 802.3i / 802.3u / 802.3ab / 802.3z |
| POE |
| PoE Standard |
IEEE 802.3af / 802.3at |
| PoE Ports |
8 × Gigabit PoE+ |
| PoE Power per Port |
Up to 30W |
| Total PoE Budget |
Up to 140W |
| PoE Power Supply Type |
End-Span |
| PoE Pin Assignment |
1/2(+) and 3/6(-) |
| NETWORK FEATURES |
| VLAN |
802.1Q VLAN / Management VLAN / Private VLAN / Voice VLAN / Protocol-Based VLAN / MAC-Based VLAN / Q-in-Q |
| Static Routing |
Supported |
| DHCP Server |
Supported |
| DHCP Snooping |
Supported |
| IGMP Snooping |
Supported |
| Link Aggregation |
Supported |
| Loop Prevention |
Supported |
| QoS |
Supported |
| Bandwidth Control |
Supported |
| STP |
STP / RSTP / MSTP |
| SECURITY |
| ACL |
L2–L4 Access Control List |
| 802.1X |
Supported |
| Port Security |
Supported |
| IP-MAC-Port Binding |
Supported |
| DoS Defense |
Supported |
| Storm Control |
Supported |
| DHCP Snooping |
Supported |
| SFP |
| SFP Slots |
2 × 1000Mbps SFP |
| Uplink Speed |
1Gbps |
| Fiber Connectivity |
Supported with Compatible 1000Mbps SFP Modules |
| MANAGEMENT |
| Web Management |
Supported |
| CLI |
Console / Telnet / SSH |
| Cloud Management |
Wi-Tek Cloud |
| SNMP |
SNMP v1 / v2c / v3 |
| RMON |
Supported |
| LLDP |
IEEE 802.1AB |
| NTP / SNTP |
Supported |
| Firmware Upgrade |
Supported |
| Configuration Backup |
Supported |
| Cloud VLAN Configuration |
Supported |
| Topology Display |
Supported |
| POWER & GENERAL |
| Power Supply |
AC 100–240V, 50/60Hz |
| Power Consumption |
14.2W Idle / Up to 154.2W at 100% Traffic with PoE |
| Dimensions |
280 × 180 × 44mm |
| Installation |
Rack Mount / Desktop |
| Fan |
Fanless |
| Operating Temperature |
-10°C to 50°C |
| Storage Temperature |
-40°C to 70°C |
| Operating Humidity |
10%–90% RH, Non-Condensing |
Note: The Wi-Tek WI-PCMS310GF V2 is a Cloud L2+ Managed Gigabit PoE Switch featuring 8 × 10/100/1000Mbps PoE+ ports, 2 × 1000Mbps SFP uplink slots and 1 × console port. It supports IEEE 802.3af/at PoE with up to 140W total PoE budget, 20Gbps switching capacity, Static Routing, VLAN, QoS, Link Aggregation, STP/RSTP/MSTP, ACL, DHCP Snooping, SNMP, RMON and Wi-Tek Cloud management.
Important: The WI-PCMS310GF V2 is a Layer 2+ Gigabit Managed PoE+ Switch with 8 × 10/100/1000Mbps PoE ports and 2 × 1000Mbps SFP uplink slots. Each PoE port supports up to 30W, with a total PoE budget of 140W. It also supports Static Routing, VLAN, ACL, DHCP Snooping, STP/RSTP/MSTP, QoS, Link Aggregation, SNMP, RMON and Wi-Tek Cloud management. Unlike the WI-PCMS310GF-O V2, this model is designed for indoor/rack installation and is not an outdoor IP-rated switch.
