DAHUA EAP6218-C

AX1800 Ceiling Mount Wi-Fi 6 Access Point

  • Dual-band Wi-Fi 6 access point with up to 1.775Gbps wireless speed
  • 574Mbps on 2.4GHz and 1201Mbps on 5GHz
  • 1 × Gigabit WAN PoE port and 1 × Gigabit LAN port
  • Supports MU-MIMO, OFDMA, Beamforming and seamless roaming
  • Supports FIT AP, FAT AP and Gateway operating modes
  • Omnidirectional antennas with 12VDC or 802.3af/at PoE power
หมวดหมู่: , , ป้ายกำกับ:

Specifications DAHUA EAP6218-C

Features Description
Product Type AX1800 Ceiling Mount Wireless Access Point
Wireless Standard IEEE 802.11a/b/g/n/ac/ax
Wireless Speed 2.4 GHz: 574 Mbps; 5 GHz: 1201 Mbps; Total: 1.775 Gbps
Antenna Gain 2.4 GHz: 4.6 dBi; 5 GHz: 4.0 dBi
Ethernet Ports 1 × Gigabit WAN/PoE; 1 × Gigabit LAN
Power Supply 12VDC / 1.5A; PoE 802.3af / 802.3at
Installation Ceiling Mount / Wall Mount
Wireless
Wireless Standard 2.4 GHz: IEEE 802.11b/g/n/ax
5 GHz: IEEE 802.11a/n/ac/ax
Operating Frequency 2.4 GHz–2.484 GHz; 5.150 GHz–5.850 GHz
Wireless Transmission Rate 2.4 GHz: 574 Mbps; 5 GHz: 1201 Mbps
Channel Width 2.4 GHz: 20 / 40 MHz; 5 GHz: 20 / 40 / 80 MHz
Antenna Type Omnidirectional
Antenna Gain 2.4 GHz: 4.6 dBi; 5 GHz: 4.0 dBi
Antenna Direction Angle 360°
MU-MIMO Yes
OFDMA Yes
Beamforming Yes
Optimal Transmission Distance 15 m
Maximum Transmission Distance 20 m
Network & Management
WAN / PoE Port 1 × 10/100/1000 Mbps Base-T RJ-45, PoE In
LAN Port 1 × 10/100/1000 Mbps Base-T RJ-45
Operating Mode FIT AP / FAT AP / Gateway Mode
VLAN VLAN configuration based on SSID
DHCP Supported
NAT Supported in Gateway Mode
QoS Supported
Management Web / Platform / App
Remote Management AC Remote Management / DoLynk Care
Firmware Update Web Update / AC Remote Update
Security
Encryption WPA-PSK / WPA2-PSK / WPA2/WPA3-PSK
MAC Authentication Supported
IP Address Filtering Supported
MAC Address Filtering Supported
User Isolation Supported
SSID Hiding Supported
Maximum Wireless Terminals 2.4 GHz: 64; 5 GHz: 64
Wireless Features
Seamless Roaming Supported
Auto Channel Supported
Power Adjustment Supported
5 GHz Precedence Supported
SSID Extender Supported
Wi-Fi Timer Supported
VPN Pass-through Supported
802.11k / 802.11v Supported
WMM Supported
Hardware & Power
Memory DDR: 256 MB
Flash 16 MB
Power Supply 12VDC / 1.5A; 802.3af PoE; 802.3at PoE
PoE Input 802.3af
Power Consumption 12.2W Full Load; 5W Idle
Indicators SYS / WAN-PoE / LAN
Physical & Environment
Dimensions 186 × 186 × 36 mm
Net Weight 0.41 kg
Operating Temperature -10°C to +45°C
Storage Temperature -40°C to +70°C
Operating Humidity 5%–95% RH, Non-condensing
Static Protection Air Discharge: 8 kV; Contact Discharge: 6 kV
Lightning Protection Common Mode: 2 kV; Differential Mode: 1 kV
Installation In-Ceiling Mount / Wall Mount
Certification CE

Note: The DAHUA EAP6218-C is an AX18 Wi-Fi 6 indoor ceiling access point with dual-band speeds of up to 574 Mbps on 2.4 GHz and 1201 Mbps on 5 GHz.

Important: Specifications are based on the EAP6218-C_datasheet_20240909. Actual wireless performance and coverage may vary depending on installation, obstacles, interference, client devices, and environmental conditions.
