System Parameters

• Processor32-bit

General

• Power Supply12V DC
• Working Temperature-20°C to +65°C (-4°F to +149°F)
• Working Humidity10% to 90% (Non Condensing)
• Working Current≤500mA
• Reading Frequency13.56MHz
• Reading Range≤50mm (≤1.97″)
• ID Settingsvia DIP Switch
• Audio AlertBeeper
• Power Consumption≤2W
• KeypadNo Keypad ( DS-K1101M )Keypad with 12 Keys (0 to 9, *, #) ( DS-K1101MK)
• CertificationsFCC, CE
• LED IndicatorPower Indicator; Status LED Indicator
• Protection LevelIP 64
• Dimensions132.0mm × 92.3mm × 20.5mm (5.20” × 3.63” × 0.81″)
• Weight≤0.14Kg
• Installing MethodApplied for 120 Gang Box Only
