General

• Power Supply12V DC
• Working Temperature-20°C to + 65°C (-4°F to + 149°F)
• Working Humidity10% to 90% (Non Condensing)
• Working Current≤500mA
• Reading Frequency13.56MHz
• Reading Range≤50mm (≤1.97″)
• ID Settingsvia DIP Switch
• Audio AlertBeeper
• Power Consumption≤2W
• KeypadNo Keypad (DS-K1104M)Keypad with 12 Keys (0 to 9, *, #) (DS-K1104MK)
• CertificationsFCC, CE
• LED IndicatorPower Indicator; Status LED Indicator
• Protection LevelIP 65
• Dimensions118 mm × 76 mm × 23 mm (4.65” × 2.99” × 0.91″)
• ≤ 0.52kg
• Installing MethodApplied for 86 & 120 Gang Box

system parameters

• Processor32-bit
