General

• Working Temperature-10°C~+55°C (14°F~131°F)
• Working Humidity0~95% (Relative Humidity)
• Working Current340mAx2
• LED IndicatorGreen (Work Status)
• Dimension Of Lock Body (L×W×H)238×45×25mm (9.4×1.8×1.0″)
• Dimension Of Armature Plate (L×W×H)182×38×12.5mm (7.2×1.5×0.5″)
• Unlock MethodCurrent Interruption
• Maximum Thrust280kg(550Lbs) Linear Thrust
• Input Voltage12 VDC
• Suitable DoorWooden Door, Glass Door, Metal Door, Fireproof Door
• Surface Temperature≤ Ambient Temperature +20°C (68°F)
• ShellHard Anodizing Electroplating Operated
• Lock BodyEco-friendly Nickel Electroplating Operated
• Armature PlateEco-friendly Zinc Electroplating Operated
• 2.1kg
