General

• Working Temperature-10°C to +55°C (14°F to 131°F)
• Working Humidity0 to 95% (relative humidity)
• Dimension (L×W×H)90×35×28.9mm(3.54×1.38×1.14″)
• Structurealuminum alloy panel, metal button
• Current Rating3A@36VDC Max
• Output ContactNO/NC/COM Contact
• Aging Testalready passed 500 thousand times aging test
• Panelaluminum panel with sandblast
• Product Weight0.20kg (0.44lb)
• Suitable Doorshollow doorframe and embedded-electric box
