4 Core OM3 Outdoor/Indoor All-Dielectric Fiber Optic Cable

  • 4 Core OM3 50/125μm Multimode fiber optic cable
  • All-Dielectric single loose tube design for indoor and outdoor installation
  • LSZH-FR jacket with UV-resistant outer sheath for enhanced safety and durability
  • Water-blocking E-glass yarn provides moisture protection and tensile strength
  • Suitable for backbone, FTTx, CATV, CCTV and high-speed Ethernet networks
  • Complies with ANSI/TIA-568.3, IEC 60794, ITU-T G.651 and RoHS standards
หมวดหมู่: , , ป้ายกำกับ:
*** ผู้รับเหมาโครงการต้องการราคาพิเศษสนใจติดต่อ ***
เบอร์มือถือ : 063-1963553 ไอดีไลน์ : ifocusshop

Specifications LINK UFC4304

Features Description
Device Type Outdoor/Indoor All-Dielectric Fiber Optic Cable
Fiber Type OM3 XG Multimode 50/125 μm
Core Count 4 Core
Cable Construction Single Loose Tube, All-Dielectric
Water Blocking Waterproof Gel Filled Tube with Water Blocking E-Glass Yarn
Strength Member Water Blocking E-Glass Yarn (Non-Metallic)
Outer Jacket UV-Resistant FR-LSZH (Low Smoke Zero Halogen)
Jacket Color Black
Cable Length 4,000 Meters / Drum
Application Campus Backbone, Building Backbone, Indoor/Outdoor Duct, Lash Aerial, Data Center, FTTx, CATV, CCTV and Enterprise Networks
Cable Standard ANSI/TIA-568.3-D, ISO/IEC 11801:2017
Fiber Standard ITU-T G.651.1 OM3 Multimode
Core Size 50/125 μm
Number of Fibers 4 Core
Fiber Construction Single Loose Tube with Waterproof Gel Filling
Strength Member Water Blocking E-Glass Yarn
Rip Cord Included
Outer Jacket UV-Resistant FR-LSZH
Cable Diameter Approximately 7.2 ± 0.5 mm
Cable Weight Approximately 53 ± 5 kg/km
SMART FEATURES
All-Dielectric Design Non-Metallic Construction Eliminates Electrical Conductivity and Grounding Requirements
OM3 XG Multimode Fiber Optimized for High-Speed Laser Transmission in Enterprise and Data Center Networks
Water Blocking Protection Gel-Filled Loose Tube and E-Glass Yarn Prevent Moisture Penetration and Improve Outdoor Reliability
LSZH Flame Retardant Jacket Provides Low Smoke and Zero Halogen Performance for Safer Indoor Installations
High-Speed Optical Transmission Supports 10G, 40G and 100G Ethernet, Fiber Channel, FTTx, CATV and CCTV Applications
GENERAL
Cable Type Outdoor/Indoor All-Dielectric Single Loose Tube Fiber Optic Cable
Maximum Tensile Load 1,800 N (Installation) / 900 N (Operation)
Maximum Crush Resistance 1,500 N / 10 cm
Minimum Bend Radius 15 × Cable Diameter (Installation), 10 × Cable Diameter (Operation)
Installation / Operating Temperature -40°C to +70°C
Storage Temperature -40°C to +75°C
Standards Compliance ANSI/TIA-568.3-D, ANSI/TIA-568-C.3, ISO/IEC 11801:2017, IEC 60793, IEC 60794-1-2, IEC 60332-1-2, IEC 61034-2, IEC 60754-2, Telcordia GR-20-CORE, GR-409-CORE, TIS 2165, RoHS
Packaging 4,000m Drum
Warranty 30 Years

Note: The LINK UFC4304 is a 4-core OM3 XG 50/125 μm multimode fiber optic cable designed for both indoor and outdoor installations. Its all-dielectric construction, gel-filled single loose tube, water-blocking E-glass yarn, and UV-resistant FR-LSZH jacket provide high-speed optical transmission with excellent protection against moisture, UV exposure, and harsh environmental conditions.

Important: The LINK UFC4304 is optimized for laser-based OM3 applications and supports IEEE 802.3 10G, 40G and 100G Ethernet, Gigabit Ethernet, Fiber Channel, FTTx, CATV, CCTV and campus backbone networks. Its all-dielectric design eliminates grounding requirements while providing complete immunity to electromagnetic interference, making it ideal for duct and aerial backbone installations between buildings.
