| Features |
Description |
| Product Type |
Layer 3 Managed Modular Service Module |
| Compatible Chassis |
RG-NBS6002 |
| Network Layer |
Layer 3 |
| SFP Ports |
16 × Gigabit SFP |
| RJ45 Ports |
8 × 10/100/1000BASE-T |
| SFP+ Ports |
2 × 10G SFP+ |
| PoE |
Not Supported |
| PORTS |
| Gigabit SFP Ports |
16 × SFP |
| Gigabit RJ45 Ports |
8 × 10/100/1000BASE-T |
| 10G SFP+ Ports |
2 × SFP+ |
| RJ45 Port Speed |
10/100/1000 Mbps |
| SFP Port Speed |
1 Gbps |
| SFP+ Port Speed |
10 Gbps |
| Indicators |
Status and Link/ACT Indicators |
| MODULE |
| Module Type |
Service Module / Line Card |
| Chassis Compatibility |
RG-NBS6002 |
| Hot Swapping |
Not Supported |
| Transceiver Support |
Supported SFP/SFP+ Transceiver Modules |
| Copper Cable |
Supported on RJ45 Ports Only |
| POWER & ENVIRONMENT |
| Power Consumption |
< 36.4W |
| Operating Temperature |
0°C to 50°C |
| Storage Temperature |
-40°C to 70°C |
| Operating Humidity |
10% to 90% RH, Non-Condensing |
| MTBF |
> 200,000 Hours |
| PHYSICAL |
| Dimensions (H × W × D) |
40.3 × 227 × 210 mm |
| Weight |
0.95 kg |
| Certification |
CE |
Note: The M6000-16SFP8GT2XS is a modular service module designed for the RG-NBS6002 chassis, providing both fiber and copper connectivity with 10G uplink ports.
Important: This module is not a standalone switch. It must be installed in a compatible RG-NBS6002 chassis. SFP and SFP+ ports require compatible transceiver modules for fiber connectivity.
