NVR5224-24P-4KS2

NVR5208-4KS2

NVR5224-24P-4KS2

Dahua รุ่น NVR5224-24P-4KS2

24Channel 1U 24PoE 4K&H.265 Pro Network Video Recorder

> สัญญาณเข้ารหัสแบบ H.265+/H.265/Smart H.264+/H.264/MJPEG
> รองรับ Bandwith สูงสุด 320 Mbps
> รองรับภาพสูงสุด 12 ล้านพิกเซล
> ซัพพอร์ท IPC UPnP, 24 PoE ports
> ซัพพอร์ท 3D intelligent positioning with Dahua PTZ camera
หมวดหมู่: , , ,
*** ผู้รับเหมาโครงการต้องการราคาพิเศษสนใจติดต่อ ***
เบอร์มือถือ : 063-1963553 ไอดีไลน์ : ifocusshop
System
Main Processor Quad-core embedded processor
Operating System Embedded LINUX
Audio and Video
IP Camera Input 24 Channel
Two-way Talk 1 Channel Input, 1 Channel Output, RCA
Display
Interface 1 HDMI (up to 3840 x 2160), 1 VGA
Resolution 3840 × 2160 , 1920 × 1080 , 1280 × 1024,

1280 × 720 , 1024 × 768
Multi-screen Display 1/4/8/9/16/25
OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
Compression Smart H.265+/H.265/Smart H.264+/H.264/MJPEG
Resolution 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 1.3MP, 720P, D1 etc.
Record Rate 320Mbps
Bit Rate 16Kbps ~ 20Mbps Per Channel
Record Mode Manual, Schedule (Regular, MD(Motion Detection) , Alarm, IVS), Stop
Record Interval 1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Video Detection and Alarm
Trigger Events Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Video Detection Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Tampering
Alarm input 4 Channel, Low Level Effective, Green Terminal Interface
Relay Output 2 Channel, NO/NC Programmable, Green Terminal Interface
Playback and Backup
Sync Playback 1/4/9/16
Search Mode Time /Date, Alarm, MD and Exact Search (accurate to second)
Playback Function Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom
Backup Mode USB Device/Network
Third-party Support
Third-party Support Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more
Network
Interface 1 RJ-45 Ports (10/100/1000Mbps)
Ethernet Port 1 Independent 1000Mbps Ethernet Ports
PoE 24 ports (IEEE802.3af/at)
Network Function HTTP, HTTPs, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, IP Search (Support IP camera, DVR, NVS, etc.)
Optical Fiber Interface N/A
Max. User Access 128 users
Smart Phone iPhone, iPad, Android
Interoperability ONVIF 2.4, CGI Conformant
Storage
Internal HDD 2 SATA III Ports, Up to 8 TB capacity for each HDD
HDD Mode Single
eSATA N/A
SAS N/A
Auxiliary Interface
USB 2 USB Ports (1 Rear USB 3.0 , 1 Front USB 2.0 )
RS232 1 Port, for PC Communication and Keyboard
RS485 N/A
Electrical
Power Supply Single, AC100V ~ 240V, 50 ~ 60 Hz
Power Consumption <16W (Without HDD)
Environmental
Operating Conditions -10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa
Storage Conditions -20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH
Construction
Dimensions 1U, 440mm x 419.96mm x 43.65mm ;

(17.3″ x 16.5″ x 1.7″)
Net Weight 4.5kg (9.9 lb) (without HDD)
Gross Weight 6.45kg (14.2 lb)
Installation Rack-mounted
Certifications
CE EN55032, EN55024, EN50130-4, EN60950-1
FCC Part 15 Subpart B, ANSI C63.4-2015
UL UL 60950-1 and CAN/CSA C22.2 No.60950-1
