Specifications RUIJIE RG-AP680(CD)
| Features | Description |
|---|---|
| Product Type | Outdoor Wi-Fi 6 Dual-Radio Wireless Access Point |
| Wi-Fi Standard | IEEE 802.11a/b/g/n/ac/ax |
| Radio Design | Dual-Radio, Up to 4 Spatial Streams |
| Maximum Data Rate | 2.402 Gbps |
| Operating Mode | Fat / Fit / Cloud Mode |
| IP Rating | IP68 |
| WIRELESS | |
|---|---|
| Radio 1 | 2.4 GHz / 5 GHz, 2×2 MU-MIMO |
| Radio 2 | 5 GHz, 2×2 MU-MIMO |
| 2.4 GHz Data Rate | Up to 574 Mbps |
| 5 GHz Data Rate | Up to 1.201 Gbps |
| Combined Data Rate | Up to 2.402 Gbps in 5 GHz + 5 GHz mode |
| Wireless Technology | OFDMA, MU-MIMO, 1024-QAM, Beamforming |
| Channel Bandwidth | Up to 80 MHz |
| ANTENNA | |
|---|---|
| Antenna Type | Built-in Intelligent Directional Antennas |
| 2.4 GHz Gain | 9 dBi |
| 5 GHz Gain | 9 dBi |
| Maximum Transmit Power | 28 dBm |
| Antenna Beamwidth | Approximately 60° Horizontal / 30° Vertical |
| NETWORK & PORTS | |
|---|---|
| Ethernet Port | 1 × 10/100/1000BASE-T |
| Optical Port | 1 × 1GE SFP |
| Console Port | 1 × RJ45 Console Port |
| Management | Ruijie Cloud / Web / CLI |
| WDS | Supported |
| Maximum Associated Clients | Up to 1,024 |
| Recommended Active Devices | Up to 120 per AP |
| BLUETOOTH | |
|---|---|
| Bluetooth | Bluetooth 5.0 |
| Antenna | Integrated Omnidirectional Antenna |
| Antenna Gain | 4.5 dBi |
| Maximum Transmit Power | 10 dBm |
| SECURITY | |
|---|---|
| Authentication | PSK, Web, 802.1X, RADIUS, WPA, WPA2 and WPA3 |
| Encryption | WEP, WPA-Personal, WPA-Enterprise, WPA2/WPA3 and WPA3-Enterprise |
| SSID Management | SSID Hiding, Authentication, Encryption and VLAN Assignment |
| STA Management | Client Identification, Load Balancing and Rate Limiting |
| Wireless Roaming | Layer 2 and Layer 3 Roaming |
| POWER | |
|---|---|
| DC Input | 48V DC / 0.35A |
| PoE Input | IEEE 802.3af / 802.3at |
| Maximum Power Consumption | 12.95W |
| Idle Power Consumption | 6.0W |
| Power Priority | DC Power Preferred When Both DC and PoE Are Available |
| ENVIRONMENT & PROTECTION | |
|---|---|
| Operating Temperature | -40°C to +65°C |
| Storage Temperature | -40°C to +85°C |
| Operating Humidity | 0% to 100% RH, Non-Condensing |
| IP Rating | IP68 |
| Surge Protection | Up to 9 kV |
| MTBF | >250,000 Hours |
| PHYSICAL | |
|---|---|
| Dimensions (W × D × H) | 251 × 168 × 64 mm |
| Weight | 1.17 kg |
| Mounting | Wall / Pole Mount |
| Mounting Bracket | Included |
Note: The RG-AP680(CD) is an industrial-grade outdoor Wi-Fi 6 access point designed for harsh environments, with built-in directional antennas, 1GE SFP connectivity and Gigabit Ethernet.
Important: Wireless frequency bands and maximum transmit power may vary according to country or regional regulations. The DC power adapter and PoE power source are purchased separately.
